FEATURES
Compatible with PAL DVD (Video
CD) and NTSC DVD (Video CD)
This player can play discs recorded in
either PAL or NTSC format.
- A single LSI chip now integrates all
major DVD playback circuit functions
including MPEG2 decoder, video D/A
converter, and audio decoders.
- L/R stereo analog audio outputs for
connection to existing head unit aux
inputs. Video output is composite
video.
- Supplied remote handles multi-function
software (multi-language audio-
track/subtitle, multi-angle, multi-
story, etc.), plus all basic functions.
USE THIS PRODUCT SAFELY
This set has been designed and
manufactured to assure personal safety.
Improper use can result in electric shock
or fire hazard. The safeguards
incorporated in this unit protect you if
you observe the following procedures for
installation, use and servicing. This unit
doesnt contain any parts that can be
repaired by the user.
When Driving
Keep the volume level low enough to be
aware of road and traffic conditions.
When Car Washing
Do not expose the product to water or
excessive moisture. This could cause
electrical shorts, fire or other damage.
When Parked
Parking in direct sunlight can produce
very high temperatures inside your
vehicle. Give the interior a chance to
cool down before starting playback.
Use the Proper Power Supply
This product is designed to operate with
a 12 volt DC, negative ground battery
system (the regular system in a North
American car).Protect the Disc Mechanism
Avoid inserting any foreign objects into
the slot of this player.
Failure to observe this may cause
malfunction due to the precise
mechanism of this unit.
Use Authorized Service Centres
Do not attempt to disassemble or adjust
this precision product. Please refer to
the Service Centre list included with this
product for service assistance.
For Installation
The unit should be installed in a
horizontal position with the front end up
at a convenient angle, but not more than
30°.
Protect the Monitor Mechanism
- The monitor is operated automatically.
Do not draw the monitor out or turn it
upward or downward manually.
Otherwise, the mechanism
construction may be harmed to some
degree.
- When you operate the monitor with the
remote handset, do not touch the
monitor by your hands. It may harm
your fingers.
Page 2
Safety Information ......................................................................................................4
Disc Notes ...................................................................................................................5
Installation ...................................................................................................................6
The Player ...................................................................................................................8
Front View ...............................................................................................................8
Back View ...............................................................................................................9
The Radio Box.............................................................................................................9
Electrical Connection ...............................................................................................10
Remote Control ........................................................................................................11
Location and Function of Keys .............................................................................11
Preparing the Remote Control ..............................................................................13
Loading/ Ejecting a disc ..........................................................................................13
Loading a disc ......................................................................................................13
Ejecting a Disc ......................................................................................................13
Operation...................................................................................................................14
Basic Operation ....................................................................................................14
Disc (DVD, VCD, CD, MP3) Operation ..................................................................16
Radio Operation....................................................................................................20
TV Operation .........................................................................................................21
AV Operation.........................................................................................................22
RGB Operation .....................................................................................................22
Setup..........................................................................................................................23
Initial Setup ...........................................................................................................23
General Setup .......................................................................................................23
Speaker Setup ......................................................................................................25
Audio Setup ..........................................................................................................25
Preferences Setup ................................................................................................26
Defaults Table .......................................................................................................28
Trouble Shooting ......................................................................................................29
Specifications ...........................................................................................................30
Mobile TV Tuner Unit ................................................................................................31
Control & Function Keys ..........................................................................................32
3
CONTENTS
