12 high level input connections
electrical connections
stereo input connections
2/4 channel input connections
mono input connections
features and specifications PLMRA220
features and specifications
general features 2
congratulations...
table of contents
PLMRA420
PLMRA220/PLMRA420
PLMRA220
PLMRA220
PLMRA420
PLMRA420 3-4
5-6
7-8
9
10
11
14 high level mono input connections
15 speaker connections
16 speaker connections
13 mono input connections
17 speaker connections
mounting and installation 18 protection circuitry and troubleshooting 19 precautions 20
PLMRA420
PLMRA420
PLMRA220
PLMRA420
PLMRA420
on your purchase of a Pyle
Marine
Series amplifier. This amplifier extends the Pyle tradition into a totally new series of amps, designed
from the ground up to deliver the power, performance and flexibility
the modern car audio enthusiast demands.
When you check the list of features offered by the PLMRA220,PLMRA420
youll
know you made the right choice with a Pyle
Marine
amplifier.
Page 2
· 300 Watts x 2 Output
· 600 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs· High Level MOLEX Input· Power ON LED Indicator· LED Protection Indicator· S/N Ratio: > 95 dB· THD: <0.04%· Thermal Protection· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLMRA220High Performance 600 Watt 2 Channel Bridgeable MOSFET Amplifier
2
general features
· 250 Watts x 4 Output. · 500 W x 2 Bridged Output ( 250 W x 2 + 500 W x 1)
· Dual Variable Hi/Lo Electronic Crossover Network
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs· High Level MOLEX Inputs· Power ON LED Indicator· LED Protection Indicator· S/N Ratio: > 95 dB· THD: <0.04%· Thermal Protection· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Tri-Mode Configurable · Blue LED Level Display
PLMRA420High Performance 1000 Watt 4 Channel Bridgeable MOSFET Amplifier
3
features and controls 2 ch amp PLMRA220
speaker connections power terminals power fuse
high level inputs
protection LEDpower LED
crossover mode selectorinput level controlbass boost level
low level inputs
low pass frequency controlhigh pass frequency control
PLMRA220
