Thank you for purchasing the TFT LCD color monitor, To enjoy the
features of this device and to ensure years of trouble-free operation,
please read this manual carefully and follow the instructions.
Front Panel
1. earphone jack
3. Negative adjustment
5. Activation of Menu Indicator
7. Light
Remote control
r:
1 i 13
2- a r 3
4 -i < - se 5
6 7
8 .-9
1o , -11
mm;
K-J
2. Audio/Video input
4. Positive adjustment
6. Power ON/OFF
8. Remote sensor
1.Power On/Olf
2.Brightness -
3.Brightness +
4.Colour -
5,Co|our+
6.Contrast -
7.Contra5t +
8.Volume -
9.Vo|ume +
10.V1/V2
11.Piclure Swivel
Contents and specifications can be subjected to change without prior notice.
HTTP: N WWW.PYLECARAUDIO. COM
Basic operation
1. Make sure the video and power connection are properly executed.
2. Press MENU to display the adjustments in this order.
Brightness-->Co|or-->Contrast-->Vo|ume-->Brightness...
3. Adjust the values by pressing AN+ or AN- .
4. The POWER button activates/deactivates the monitor. It is not
Necessary to disconnect the power source.
W
Screen Size: 7 inch
System: NTSC/PAL
Power source: DC12V i10%
Power consumption: < 9W
Video Input: Composition Video Signal
Operating Temperature: 0°C -> 60°C
Storage Temperature: - 20°C a 80°C
Headrest bracket
With stand
Accessory
1 x bracket
1 x remote control
2 x connection wire
1
Suitable for any kinds of car
seats. Easy and conveniently
installation without damage
to the seats. Length can be 2
l
adjusted(as Picture). am
1 x headrest shroud
1 x user's manual
