Page 1
Safety Information......................... 4Disc Notes...................5Installation ...................6The Player.....................9Front View......................9Back View........................10Electrical Connection ....................11Remote Control ....................12Location and Function of Keys.....................12Preparing the Remote Control.....................14Loading/ Ejecting a disc .....................15Loading a disc.............................15Ejecting a Disc...............................15Operation ..................................16Basic Operation...................................16Disc (DVD, VCD, CD, MP3) Operation...................18...................................22RGB OperationSetup.........................................23Initial Setup........................................23General Setup....................................23Speaker Setup.......................................25Audio Setup........................................25Preferences Setup....................................26Defaults Table.........................................29Trouble Shooting ................................30Specifications.....................................322CONTENTS
Page 2
3FEATURESCompatible with NTSC DVD
(Video CD) This player can play discs recorded ineither NTSC format. A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders.L/R stereo analog audio outputs for connection to existing head unit aux inputs. Video output is composite video.Supplied remote handles multi-functionsoftware (multi-language audio-track/subtitle, multi-angle, multi-story, etc.), plus all basic functions.USE THIS PRODUCT SAFELYThis set has been designed andmanufactured to assure personal safety.Improper use can result in electric shockor fire hazard. The safeguardsincorporated in this unit protect you ifyou observe the following procedures forinstallation, use and servicing. This unitdoesn't contain any parts that can berepaired by the user.When DrivingKeep the volume level low enough to beaware of road and traffic conditions.When Car WashingDo not expose the product to water orexcessive moisture. This could causeelectrical shorts, fire or other damage.When ParkedParking in direct sunlight can producevery high temperatures inside yourvehicle. Give the interior a chance tocool down before starting playback.Use the Proper Power SupplyThis product is designed to operate witha 12 volt DC, negative ground batterysystem (the regular system in a NorthAmerican car).Protect the Disc MechanismAvoid inserting any foreign objects intothe slot of this player.Failure to observe this may causemalfunction due to the precisemechanism of this unit.Use Authorized Service CentresDo not attempt to disassemble or adjustthis precision product. Please refer tothe Service Centre list included with thisproduct for service assistance.For InstallationThe unit should be installed in ahorizontal position with the front end upat a convenient angle, but not more than30.Protect the monitor mechanicalThe monitor is operated automatically.Do not draw the monitor out or turn itupward or downward manually.Otherwise, the mechanismconstruction may be harmed to somedegree.When you operate the monitor with theremote handset, do not touch themonitor by your hands. It may harmyour fingers.
