2FEATURESCompatible with NTSC DVD (Video CD) This player can play discs recorded ineither PAL or NTSC format.A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders.L/R stereo analog audio outputs for connection to existing head unit aux inputs. Video output is composite video.Supplied remote handles multi-functionsoftware (multi-language audio-track/subtitle, multi-angle, multi-story, etc.), plus all basic functions.USE THIS PRODUCT SAFELYWhen DrivingKeep the volume level low enough to beaware of road and traffic conditions.When Car WashingDo not expose the product to water orexcessive moisture. This could causeelectrical shorts, fire or other damage.When ParkedParking in direct sunlight can producevery high temperatures inside yourvehicle. Give the interior a chance tocool down before starting playback.Use the Proper Power SupplyThis product is designed to operate witha 12 volt DC, negative ground batterysystem (the regular system in a NorthAmerican car).Protect the Disc MechanismAvoid inserting any foreign objects intothe slot of this player.Failure to observe this may causemalfunction due to the precisemechanism of this unit.Use Authorized Service CentresDo not attempt to disassemble or adjustthis precision product. Please refer tothe Service Centre list included with thisproduct for service assistance.For InstallationThe unit should be installed in ahorizontal position with the front end upat a convenient angle, but not more than30.

Page 2

Safety Information......................... 4Disc Notes...................5Installation ...................6Wiring Connection.................1020 Pin Socket Connection..................10................11Location and Function of Keys........................11Remote Control ......................12Remote Control.........................14Preparing the Remote Control........................14Loading/ Ejecting a disc ......................15Loading a disc..............................15Ejecting a Disc................................15Operation .................................16Basic Operation....................................16Disc (DVD, VCD, CD, MP3) Operation....................17......................18AV IN OperationSetup...............................22Initial Setup.............................................23General Setup........................................23.......................................23Audio Setup.........................................25Preferences Setup....................................26Defaults Table.........................................28Trouble Shooting ................................29Specifications....................................303CONTENTSThe PlayerRadio OperationUsing the Detachable Front Panel .............................9
