Page 1
1
Power
Volume
Eject
Release
Mode
Loud
Clock
EQ Volume setting
Bass setting
Treble settting
Balance setting
Fader setting
Seek
Play/Pause
Scan
Repeat
Shuffle Band
Loc
Tune
St
Radio wiring
Speaker wiring Install the unit
Removing the unit
USB PLAYER
AUX IN Loading and Replacing the battery
Basic operation
Page 2
2
To prevent injur y or fire,take the
following precautions:To prevent damage to the machine,
take the following precautions:
Insert the unit until it is firmly locked to the
main unit, otherwise it may
fall out of place when jolted
When extending the ignition, memory
back up or ground cable, use diameter of
0.75mm(AWG18) or
more automotive grade cable to avoid wire
deterioration or damage
to the wire coating.
To prevent short circuit, never put or leave
any metallic object into the unit.
If you smell or see smoke, turn off the
power immediately and consult your dealer.
Be careful not to drop or shock the unit
strongly, it may break or crack because it
contain glass parts.
Be sure the unit is connected to a 12V
DC power with a Negative Ground
The unit is only designed for use with 4
speakers. Do not combine output for use
with 2 speakers. Do not ground negative
speaker leads to the chassis ground
Do not open the top cover and do not install
theunitin
place where it is exposed to direct sunlight
(including the faceplate),in order to avoid high
heat or humidity, water splash over it or dust.
Do not touch the terminals of the units.
Attaching panel
Attach the front panel by fixing
the right side of it into this unit as1
showing.Then push the left side
of panel towards into connecting
plug as 2 showing.
If you have difficulty in installing this unit
in your vehicle. Please contact your dealer.
If the unit seems not work in properly press
the reset button to reset the memor y of the
unit.
Attaching panel
