P / N : 570-F10602-03
OPERATING INSTRUCTIONS
LOCATION OF CONTROLS FIGURE A
1. POWER ON/OFF CONTROL
Press the button to turn the power ON or OFF.
Note : The unit can be turn on by pressing any keys on the panel (except panel release button & disc eject
button). It will help the user who cannot find the power button in dark.
2. BAND SELECTOR
Each time this button is pressed, the radio band is changed. The indication FM1, FM2, FM3, MW1 or
MW2 will appear on the display according to your selection.
3. SCAN CONTROL
Press this button to scan the receivable FM / MW stations. When receivable stations are tuned in, they are
monitored for approximately 5 seconds before advancing to the next receivable station. Press SCAN button
once again to stop scanning as desired.
4. PRE-SCAN/AUTO-STORE BUTTON
This button allows you to enjoy Preset Memory Scan function by pushing it shortly, and Auto-Store Memory
function by pushing it more than 2 seconds.
* PS (PRESET MEMORY SCAN) - It calls the memorized station frequencies ( from 1-6 ) automatically every
5 seconds.
* AS (AUTO-STORE MEMORY) - It searches all station frequencies upward and memorize automatically 6
stations by catching the frequency which has scan-stop level, the memorized station is shown on LCD as
CH1...6. After memorizing, auto-store memory function will be changed to Preset Memory Scan
function automatically.
5. DISC SLOT
Holding the disc and insert into the disc slot. The CD mechanism will automatically engage into CD play
mode.
6. LCD DIGITAL DISPLAY
The unit utilizes a digital type display which shows numerical indication of station FREQUENCY and other
FUNCTIONS.
7. CLOCK CONTROL
During radio and CD operation, press this button to call the time display on the incorporated quartz clock.
SETTING CLOCK TIME
1. Press CLOCK button and hold it until the display flash and release.
2. Press + button to set HOUR and press - to set MINUTE.
8. STEREO/MONO CONTROL
Press this button to select FM STEREO or MONO reception.
Page 2
P / N : 570-F10602-03
Page. 3
9. EJECT BUTTON
Press the button to eject the disc inside disc slot.
10. PANEL RELEASE BUTTON (FIGURE A)
To detach the front panel, press the release button so that the panel fold down from vertical position to
horizontal position and then pull it off of the chassis at horizontal position.
To re-attach the panel, push the fold-down metal frame forward until it locks to the original postion. Then, put the
panel at the right side of the position first and then press the left side of the panel until the mechanism lock it
into place.
11. MODE SELECTION
Press this button to select Radio (TUNER), CD (S-CDP), or Auxiliary input (AUX) mode.
12. LOCAL/DISTANT SELECTOR
Press this button to prevent strong local stations from overlapping weaker stations. For normal operation, press
this button again for distance.
13. LOUD CONTROL
Press this button to activate the loudness circuitry which compensates for loss of high and low frequencies
during low volume levels.
14. MUTE CONTROL
Press this button to mute the volume control and MUT will appear on LCD display.
15. AUDIO / SETTING SELECT
Briefly press the button to select volume, bass, treble, balance or fader adjustment in cyclical mode.
When pressing the button for more than 2 seconds, it activates as unit setting selection in cyclical mode as
following. The unit setting can be changed by using either VOL + or VOL -“ button.
· DSP OFF/ POP M/ ROCK M/ CLASS M/ FLAT M
· BEEP OFF/ BEEP ON (not available for this model)
· SEEK 1 (tune up/down button performs fast tune function) / SEEK 2 (performs auto tuning function when tune up/
down button pressed more than 1 second)
· COLOR 1 / COLOR 2 (not available for this model)
· VOL LAST / VOL ADJ (preset volume level when unit turn on)
16/17. AUDIO LEVEL DOWN/UP CONTROL ( - Button ) / ( + Button )
Press SEL button shortly and then pressing + or - button to adjust level of volume, bass, treble, balance or fader.
- VOLUME - Press the (+) button to increase, or (-) button to decrease volume level.
- BASS - While BASS is being displayed, press (+) button to increase or (-) button to decrease the bass level.
- TREBLE - While TREB is being displayed, press (+) button to increase or (-) button to decrease the treble level.
- BALANCE - While BAL is being displayed, press (+) or (-) button to level balance of speaker right and left.
- FADER - While FAD is being displayed, press (+) or (-) button to level fader of speaker front and rear.
18/19. MANUAL UP/DOWN TUNING / TRACK SEEK UP/DOWN CONTROL
On radio mode, press the button will tune one frequency step higher or lower. Pressing the button more than 1
second can performs fast tuning function or auto tuning function.
On CD mode, press this button will locate the beginning of the track being played or will locate the beginning
of the next track. When pressing more than 2 seconds, it will move fast forward or fast backward to a specific
position of a CD track.
20. STATION PRESET BUTTON (1-6)
The PRESET BUTTONS on the unit are used to store station frequencies which you may wish to recall. Each
preset button can store FM1, FM2, FM3, MW1, MW2 station frequency. Pressing the button momentarily recalls
the station frequency which was memorized. There are 6 preset buttons, giving you capability of storing
18FM / 12MW.
NOTE: When the preset button to be memorized is kept pressed for more than 2 seconds, the receiving station
frequency will be stored in the button pressed. After this, the memorized station can be recalled by pressing the
button once.
On CD Mode
- Preset 1 - press this button to pause the disc played.
- Preset 2 - press this button to scan the first 10 seconds of all the tracks on the currently selected disc.
- Preset 3 - press this button to repeat the current track of the disc.
- Preset 4 - press this button to play disc at random order - Disc shuffle play.
