Page 1
2
CONTENTS
HINTS FOR CORRECT AND SAFE OPERATION 2
HOW TO USE THE MAGAZINE 3
PRECAUTIONS FOR HANDLING DISCS 4
INSTALLATION PARTS 5
WIRING5
RESET FUNCTION 5
BEFORE INSTALLING THE UNIT 6
- Transport Lock Screws 6
- Installation and Wiring Precautions 6
- Position of the built-in anti-vibration Board 7
INSTALLATION 8
- Procedure for Installation on Carpet (Horizontal Position) 8
- Procedure for Installation on Carpet (Vertical Position) 9
- Procedure for Installation on Carpet (At a 45° angle) 10
- Procedure for Installation (Suspended Position) 11
HANDLING THE DISCS 12
TROUBLE SHOOTING 12
HINTS FOR CORRECT AND SAFE OPERATION
This CD Changer is designed to be operated only on +12 volt DC negative ground
systems. The unit cannot be used on +24 volt or positive ground systems.
The unit may not operate correctly in extremely hot or cold temperatures. The unit is
equipped with a built in self-protection circuit. When the temperature reaches a preset
level, the protection circuit halts all unit operations. If this should happen, open a
window and allow the car to cool.
Condensation
Moisture can condense on the laser lens of the CD changer during rainy and humid
days, or right after the heater is turned on in the car. If this should happen the unit
will not operate correctly. To remedy the situation, remove the magazine from the unit
and wait approximately one hour. During this time the moisture will evaporate and the
unit will operate normally.
Remove the magazine from the unit when it is not being used during hot weather and
the CD changer is not used for long periods of time.
Page 2
3
HOW TO USE THE MAGAZINE
Loading a disc
1. Pick the tab on the magazines disc tray
and pull out only of the trays.
2. Place the disc on the tray with its play
surface facing down (label surface facing up).
-Each tray can accommodate only one disc.
3. Press the tab on the disc tray to store
the tray back in the magazine.
-Up to ten discs can be loaded.
Installing the magazine
1. Slide the door toward the right.
2. First check that the magazine with the
discs has its top side facing up and it is
pointed in the right-direction for
installation. Push it in until clicks into
place, indicating that it is now locked.
-When the magazine is used for the first
time, it will not lock into place unless the
power supply has been connected.
-Ejecting the magazine
The magazine is ejected by pressing the
eject button ( ).
Notes:
Be absolutely sure to close the door after
having inserted or ejected the magazine.
Dust or dirt finding its way inside may
cause malfunctioning of the unit.
Eject button
Label side up
Play side down
