Page 1
> Preface
ii
COPYRIGHT AND ACKNOWLEDGMENTS
Copyright © 2002 Primare Systems AB. All rights reserved.
Primare Systems AB
Idavägen 17D
SE-352 46 Växjö
Sweden
Issue: SP31.7/2
The information in this guide is believed to be correct as of the
date of publication. However, our policy is one of continuous
development and so the information is subject to change
without notice, and does not represent a commitment on the
part of Primare Systems AB.
Primare is a trademark of Primare Systems AB. Manufactured
under license from Dolby Laboratories Dolby, Pro Logic, and
the double-D symbol are trademarks of Dolby Laboratories.
Confidential Unpublished Works. Copyright 1992-1997 Dolby
Laboratories, Inc. All rights reserved. LaserDisc is a trademark
of Pioneer Electric Corp. All other product names are
trademarks or registered trademarks of their respective
owners.
FCC Warning: This equipment generates and can radiate
radio frequency energy and if not installed and used correctly
in accordance with our instructions may cause interference to
radio communications or radio and television reception. It has
been type-tested and complies with the limits set out in
Subpart J, Part 15 of FCC rules for a Class B computing device.
These limits are intended to provide reasonable protection
against such interference in home installations.
EEC: This product has been designed and type-tested to
comply with the limits set out in EN55013 and EN55020.
This guide was produced by Human-Computer Interface Ltd,
http://www.interface.co.uk
§0 Preface26/7/02, 12:51 pm 2
Page 2
iii
> Contents
Audio inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {12
Video connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {12
Record outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {13
Microphone, data and RS232 . . . . . . . . . . . . . . . . . . . . . . . . . . {13
Connecting to the Primare A30.5
Multi-Channel Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {13
Connecting to the Primare V25 DVD Player . . . . . . . . . . . . {13
Configuring the speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {15
Setting up the speakers
Setting the speaker delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {16
Setting the speaker levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {17
Setting the analogue input level . . . . . . . . . . . . . . . . . . . . . . . . {18
Setting up the sources
Standard sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {19
Removing sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {19
Editing sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {20
Examples of sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {21
Configuring the display
Configuring the on-screen display . . . . . . . . . . . . . . . . . . . . . . {23
Configuring the front panel display . . . . . . . . . . . . . . . . . . . . . {23
Configuring the remote control . . . . . . . . . . . . . . . . . . . . . . . . . {23
Introduction
Using the SP31.7 with other Primare products . . . . . . . . . . {2
Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {2
Front panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {3
Using the SP31.7 Multi-Channel Processor
Front panel display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {3
Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {4
Selecting a source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {4
Changing the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {5
Changing the balance, center, side, rear, and subwoofer
levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {5
Advanced use
Using the main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {7
Using the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {7
Choosing the surround mode . . . . . . . . . . . . . . . . . . . . . . . . . . . {8
Making recordings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {9
Locking the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {9
Connecting the SP31.7
Back panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {11
Power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {12
Main outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . {12
§0 Preface26/7/02, 12:51 pm 3
