Primare r 20 owners manual

Page 1

>Preface ii COPYRIGHT AND ACKNOWLEDGMENTS Copyright © 2002 Primare Systems AB. All rights reserved. Primare Systems AB Idavägen 17D SE-352 46 Växjö Sweden The information in this guide is believed to be correct as of the date of publication. However, our policy is one of continuous development and so the information is subject to change without notice, and does not represent a commitment on the part of Primare Systems AB. Primare is a trademark of Primare Systems AB. All other product names are trademarks or registered trademarks of their respective owners.FCC Warning: This equipment generates and can radiate radio frequency energy and if not installed and used correctly in accordance with our instructions may cause interference to radio communications or radio and television reception. It has been type-tested and complies with the limits set out in Subpart J, Part 15 of FCC rules for a Class B computing device. These limits are intended to provide reasonable protection against such interference in home installations. EEC: This product has been designed and type-tested to comply with the limits set out in EN55013 and EN55020. This guide was produced by Human-Computer Interface Ltd, http://www.interface.co.uk §0 Preface17/4/02, 3:21 pm 2

Page 2

> iii Contents Introduction WELCOME TO THE R20 MM-MC AMPLIFIER..................................................................(1 USING THE R20 WITH OTHER PRIMARE PRODUCTS................................................................(1 TECHNICAL SPECIFICATION.............................(1 Connecting the R20 Amplifier BACK PANEL CONNECTIONS...........................(3 POWER CONNECTION........................................(4 OUTPUTS...................................................................(3 INPUTS.......................................................................(3 SETTING UP.............................................................(4 SWITCHING ON AND OFF................................(4 INCREASING THE GAIN IN MM MODE........(4 Index §0 Preface17/4/02, 3:21 pm 3
