VSX-D307-HT 2 1. CONTRAST OF MISCELLANEOUS PARTS 7 CONTRAST TABLE VSX-D307-HT/KUXJI and VSX-D307/KUXJI are constructed the same except for the following: PACKING P3 - 3 Operating Instructios (English) ARB7136 ARB7156 P3 - 5 Remote Control Unit (CU-VSX124) AXD7161 Not used P3 - 5 Remote Control Unit (CU-VSX125) Not used AXD7155 P3 - 11 Packing Case AHD7557 AHD7621 EXTERIOR SECTION P5 - 17 Rear Panel ANC7627 ANC7693 Ref. No.Remarks VSX-D307/KUXJI VSX-D307-HT/KUXJIPart No. Mark Symbol and Description NOTES :ÖParts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. ÖThe mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. ÖScrew adjacent to ° mark on the product are used for disassembly. ÖReference Nos. indicate the pages and Nos. in the service manual for the base model.
