Page 1
2
En
Thank you for buying this Pioneer product.
Please read through these operating instructions
so you will know how to operate your model
properly. After you have finished reading the
instructions, put them away in a safe place for future
reference.
Installing the Receiver
VENTILATION: When installing this unit,
make sure to leave space around the unit for
ventilation to improve heat radiation (at least 60
cm at top, 10 cm at rear, and 30 cm at each side).
WARNING: Slot and openings in the cabinet
are provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, to prevent fire hazard, the openings
should never be blocked and covered with items,
such as newspapers, tablecloths, curtains, etc.
Also do not put the apparatus on the thick carpet,
bed, sofa, or fabric having a thick pile.
H040 En
NOTE: THE NO USER-SERVICEABLE PARTS COMPARTMENT WARNING IS LOCATED ON THE APPLIANCE BONNET
Page 2
3
En
Operating Environment
Operating environment temperature and humidity:
+5°C -“ +35°C (+41°F -“ +95°F); less than 85%RH
(cooling vents not blocked)
Do not install in the following locations
- Location exposed to direct sunlight or strong
artificial light
- Location exposed to high humidity, or poorly
ventilated location
H045 En
TWO VOLTAGE SELECTOR
SWITCHES (multi-voltage
model only)
Only multi-voltage model is provided with these
switches. Mains voltages in Saudi Arabia are 127
V and 220 V only. Never use this model with the
110 V setting in Saudi Arabia.
Only multi-voltage model is provided with
this(these) switch(switches).
European models are not pro-vided with these
switches.
The line voltage selector switches are on the rear
panel. Check that they are set properly before
plugging the power cord into the household wall
socket. If the voltage is not properly set or if you
move to an area where the voltage requirements
differ, adjust the selector switches as follows.
1. Use a medium-size screwdriver.
2. First, insert the screwdriver in the groove of the
larger voltage selector, and adjust so that the tip
of the groove points to the voltage value of your
area.
3. Next, insert the screwdriver in the groove of the
amaller voltage selector and adjust until the
voltage is the same as at the larger one.
CAUTION 220 V
Power source voltage is factory adjusted 220 volts. If
your
area is different, change voltage selectors settings.
220V
230-240V 110V
120-127V
TWO VOLTAGE SELECTORS
110V 120-ˆ’127V
230
240V 220V
[For European model]
