T-Eiloo
OUTSTANDING PERFORMANCT CAPABILITIES
The mechanisms of the T-6100 are well-built, expensive,
designed for thousands of hours of fine music reproduc-
tion. lts low-distortion amplifiers features wide playback
fidelity. lts high-precision hysteresis synchronous motor
gives a constant revolution speed, even during periods of
voltage fluctuation. The machine itself is extraordinarily
quiet while it performs. And it performs to high quality
standards, too. S/N ratio is over 55d8. Frequency response
at 7 fi ips is a very wide 30-20,000H2. All the professional
specifications you'd ever want foi excellent music repro-
duction.
AUTO REVERSE
A feature usually found on more expensive tape decks,
auto reverse is the secret of a full program of uninterrupt-
ed tape music. Simply apply a small piece of sensing foil
to any spot on the tape where you wish the program to
be reversed,and the machine does the rest. You may also
reverse the tape manually by pressing a single button.
EASY-tOAD
The T-6100 threads easier than any other tape deck. You
can thread it with one hand in seconds. When you set the operating lever to its PLAY mode, the pinch roller
rises. When you set the lever to STOP, the pinch roller
slides back inside the deck. Tape protection is always
assured with the T-6100. Moreover, the stabilized pressure
between pinch roller and capstan assures constant oper-
ating conditions. lt is almost impossible to stretch and
damage a valuable tape.
PAUSE LEVER
This feature is valuable for momentarily stopping tape
motion during recording or playback. You'll want to use
it for professional editing of all your tapes.
OTHTR KTY FTATURIS
Twin level meters that light up RED during recording.
Automatic shut-off at tape end. Four-digit counter that in-
dicates position of even extra-long tapes.
SPECIFICATIONS
Drive and control:
Tracks:
Recordi n g compensation : Erasi ng:
Reel size:
Motor:
Heads:
Tape speeds: Fast winding time:
Wow and flutter:
Center capstan drive with
automatic reverse during playback, automatic playback
repetition with sensing foil, or manual operation. 4-tr ack, 2-chan nel stereo; 4-track,'1-channel mono.
NAB
AC system
Up to 7 inches
Hysteresis synchron ous motor 4-track, 2-channel recording / playback head x 1 4-tr ack, 2-cha n nel playback
head x 1
4-track, 2-channel erasing head X1
Frequency response:
Signal to noise ratio:
lnput:
Output:
Semi-conductor:
Power requirement:
Maximum power consumption: Dimensions:
(19cm/s)
Less than O.2O% at 3/a ips (9.5 cm/s)
30- 20,000H2 (SO- 15,000H2 +2dB) at 7 ft ips (19cm/s)
30-13,000H2 at 3foips (9.5cm/s)
Better than 55dB
Microphone-0.3mV to 240mY I 50k ohms
Line in -30mV to 24Y l33Okohms L ine out - 0J7 5V I 50k oh ms Headphones -0.2mW/ B ohms Transistors - 14, D iodes - 6 110, 117, 130, 220, 24OV AC, 50l6OHz
70v A
1 5 Vta (,w ) x1 4 % H)x 6'%@l i n c h es 421(W) x 378(H) x174(D)mm (including feet) Tape deck only: 261b. 7 oz.l12kg
With package: 371b. 6oz.l17kg
7)y' ips (19cmis) ,3/a ips (9.5cm/s)
Approx. 110 secs./1200 feet (370m) tape Weight: Less than 0.12% at 7 ft ips
CDrrIoNEeR
PICINEEFI ELECTFICINIC CclFIPctFIATI4N / 15-5,A-chorne, Ohrnoni-Nishi, Ohra-ku, Tokyo, Japan U'S' PIONEEFI ELECTtrION|CS COFlPOtrlAT|ON / 178 Cornrnence Road, Canlstadt, New Jensey O7O7A, U.S.A PIONEEtrl ELECTFIONIC (EUtrlOPEI N.V / Fnanknijklei 64-6E}, 2OOO Ancwenp,.Eletgiurn
[E1;11-F4| printed in Japan
