Page 2

LINE VOLTAGE AND FUSE AND REAR PANEL

Each design of LINE VOLTAGE and FUSE of this '

model differs according to each destination to be
delivered.

How to operate the SX-939 is quite the same for
each version. However, each rear panel differs
according to LINE VOLTAGE and FUSE designed
for each version.

Fig. A shows the LINE VOLTAGE of a 220V only
model.

Fig. B shows the LINE VOLTAGE and FUSE of a
5 line voltage (110V, 120V, 130V, 220V, 240V)
whose line voltage and fuse can be changed and set
as follows:

The Line VOLTAGE of a 120V only model is
illustrated Connection Diagram.

220V model

VA. ~.\\\ "
,_ \\\
i. \l\.\\\\.\\ -


5 Line Voltage modal

ac oval!
MIC-0 MIC.
tech nu: town. noon '0

cgsANGmG LINE VOLTAGE SETTING AND
F E

To remove the fuse, turn the fuse cap located on
the line voltage selector in the direction indicated ,
by the arrow. Then remove the fuse plug from the
unit. Put the fuse plug back so that the proper line
voltage marking can be seen through the cut in the
edge of the plug. Whenever the position of the
selector is changed, check the rating of the fuse.
A 3A fuse is to be used for either 220V or 240V
operation and a 6A rating for 110V, 120V or 130V
operation. If the rating of the fuse is correct,
replace cap.

FUSE REPLACEMENT

When the fuse blows, remove the fuse cap and
replace the fuse with a new one. Fig. C.

PHILLIPS
SCREWDRIVER

J SOCKET
FUSEPLUG
FUSE
FUSECAP

\i
fi ,. Fig. 0
{fl '
Fig. B
CONTE N TS
SX-939 Features .................. 3 Front Panel Facilities ............... 10
Essentials You should Know .......... 4 How to Operate the Receiver ........ 12
Connection Diagram ............... 4 Versatile Jacks for Today and
Tomorrow ..................... 14
Stereo Setup ..................... 6 "
Conditions Frequently Mistaken
Speaker Connection ................ 6 for Malfunction ................. 16
Antenna and Ground Connections ..... 7 Mounting Template ................ 17
Connections ..................... 8 Specifications ..................... 18
