Page 1
2
En
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance. The lightning flash with arrowhead, within
an equilateral triangle, is intended to alert
the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons. CAUTION:TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER -SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QU ALIFIED
SERVICE PERSONNEL.
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN
D1-4-2-3_En
Information to UserAlteration or modifications carried out without appropriate authorizatio\
n may invalidate the user s right to operate
the equipment.
POWER-CORD CAUTIONHandle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
ser vice center or your dealer for a replacement.
* Manufactured under license from Dolby
Laboratories.
Dolby , Pro Logic, and the double-D
symbol are trademarks of Dolby
Laboratories.
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which
requires repair will be charged for even during the
warranty period.
[For Canadian model]
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme à la norme NMB -003 du Canada.
IMPORTANT NOTICE -“ THE SERIAL NUMBER FOR THIS EQUIPMENT IS PRINTED ON A STICKER ON THE
PRODUCT L ABEL LOCATED ON THE UNDERSIDE OF THE TRANSMIT TER.
PLEASE WRITE THIS SERIAL NUMBER ON Y OUR ENCLOSED WARRANTY CARD AND
KEEP IN A SECURE AREA. THIS IS FOR Y OUR SECURITY.
Page 2
3
En
English
WARNING -“ TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
READ INSTRUCTIONS - All the safety and
operating instructions should be read before
the product is operated.
RETAIN INSTRUCTIONS - The safety and operating instructions should be retained for
future reference.
HEED WARNINGS - All warnings on the product and in the operating instructions should be
adhered to .
FOLLOW INSTRUCTIONS - All operating and use
instructions should be followed.
CLEANING - The product should be cleaned only with a polishing cloth or a sof t dry cloth. Never
clean with furniture wax, benzine, insecticides
or other volatile liquids since they may corrode
the cabinet.
ATTACHMENTS - Do not use attachments not recommended by the product manufacturer as
they may cause hazards.
WATER AND MOISTURE - Do not use this
product near water - for example, near a
bathtub, wash bowl, kitchen sink, or laundr y
tub; in a wet basement; or near a swimming
pool; and the like.
ACCESSORIES - Do not place this product on an
unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injur y to
a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer , or sold with the product. Any
mounting of the product should follow the
manufacturer s instructions, and should use a
mounting accessor y recommended by the
manufacturer .
CART - A product and cart combination should be
moved with care. Quick stops, excessive force,
and uneven sur faces may cause the product
and cart combination to overturn .
VENTILATION - Slots and openings in the cabinet
are provided for ventilation and to ensure
reliable operation of the product and to protect
it from overheating, and these openings must
not be blocked or covered. The openings
should never be blocked by placing the product
on a bed, sofa, rug, or other similar sur face.
This product should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer s instructions have been
adhered to .
POWER SOURCES - This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company .
LOCATION -“ The appliance should be installed in a
stable location .
NONUSE PERIODS -“ The power cord of the
appliance should be unplugged from the outlet
when lef t un-used for a long period of time.
GROUNDING OR POLARIZATION- If this product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other), it will fit into the
outlet only one way . This is a safety feature. If
you are unable to insert the plug fully into the
outlet, tr y reversing the plug. If the plug should
still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
- If this product is equipped with a three-wire
grounding type plug, a plug having a third
(grounding) pin , it will only fit into a grounding
type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet,
contact your electrician to replace your
obsolete outlet. Do not defeat the safety
purpose of the grounding type plug.
POWER-CORD PROTECTION - P ower-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
OUTDOOR ANTENNA GROUNDING - If an outside antenna or cable system is connected
to the product, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Article 810 of the National
Electrical Code, ANSI/NFP A 70, provides
information with regard to proper grounding of
the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for the
grounding electrode. See F igure A.
LIGHTNING - For added protection for this
product during a lightning storm, or when it is
lef t unattended and unused for long periods of
time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power -line surges.
POWER LINES - An outside antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can fall into such power
lines or circuits. When installing an outside
antenna system, extreme care should be taken
to keep from touching such power lines or
circuits as contact with them might be fatal.
OVERLOADING - Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY - Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short- out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
SERVICING - Do not attempt to ser vice this
product yourself as opening or removing covers
may expose you to dangerous voltage or other
hazards. R efer all servicing to qualified ser vice
personnel.
DAMAGE REQUIRING SERVICE - Unplug this product from the wall outlet and refer ser vicing
to qualified ser vice personnel under the
following conditions:
- When the power -supply cord or plug is
damaged.
- If liquid has been spilled, or objects have fallen
into the product.
- If the product has been exposed to rain or
water .
- If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions as an improper
adjustment of other controls may result in
damage and will of ten require extensive work
by a qualified technician to restore the product
to its normal operation .
- If the product has been dropped or damaged in
any way .
- When the product exhibits a distinct change in
per formance - this indicates a need for
ser vice.
REPLACEMENT PARTS - When replacement parts
are required, be sure the ser vice technician has
used replacement parts specified by the
manufacturer or have the same characteristics
as the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.
SAFETY CHECK - Upon completion of any ser vice
or repairs to this product, ask the ser vice
technician to per form safety checks to
determine that the product is in proper
operating condition .
WALL OR CEILING MOUNTING - The product
should not be mounted to a wall or ceiling.
HEAT - The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers)
that produce heat.
GROUNDCLAMP
ELECTRICSERVICEEQUIPMENT
ANTENNALEAD IN WIRE
ANTENNADISCHARGE UNIT(NEC SECTION 810-20)
GROUNDING CONDUCTORS(NEC SECTION 810-21) GROUND CL AMPS
POWER SERVICE GROUNDINGELECTRODE SYSTEM(NEC ART 250, P ART H)NEC - NATIONAL ELECTRICAL CODE
Fig. A
IMPORTANT SAFETY INSTRUCTIONS
D1-4-2-2_En
[For U.S. and Canadian model]
