QLJaPtzDLL DIRECT DRIVE 2-motor
FULL AUTOMATIC TURNTABLE
L-57.
OPERATING INSTRUCTIONS KCT
IIHII
'\
Walnut grained vinyl cabinet
I
WARNING: TO PREVENT FIRE 0R S-IOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MPIONEER MOISTURE-
Thank YOU for your purchase of the Pioneer
PL-570 quartz PLL fully-automatic turntable.
The PL-570 is a fully-automatic turntable equip-
ped with a direct-drive motor whose speed is
controlled with a high degree of precision by
a quartz oscillator and PLL circuit.
Please read this Instruction Manual carefully
clear through to the end, so that you fully
understand it before using your turntable.
CONTENTS
Installation Precautions ..................... 2
PL-570 Features . . . ................. . ...... 3
Parts Identification ......................... 4
Assembly Procedure ......... . .............. 5
Attaching the Cartridge ............... . . 6
Adjusting the Tonearm . . . . . ............... . . 7
Dust Cover ...... . ........................ 9
Connection to Stereo Amplifier ............... 9
Panel Facilities ............................ 10
Playing Procedure . . . . . . ..... . . . . ......... 12
Quartz PLL D.D. Motor Operating Principle . . . . . . 14
Turntable Care and Maintenance .............. 16
Trouble? Check It Out ...................... 18
Specifications ...... . . . ................... 19
INSTALLATION PRECAUTIONS
When installing your PL-570, please avoid the following conditions:
Conditions to be Avoided
Possible Problems Caused
o Unstable surfaces.
0 Damp or dusty location.
0 Where there are heavy vibrations, such as on top of speakers.
0 Proximity to power transformer of the amplifier.
are frequently used.
0 Exposure to direct sunlight, high temperature or high humidity.
0 Location where alcohol, insecticides, or inflammable substances
0 Can cause rust or interfere with insulation.
0 Will interfere with normal operation of turntable (jumping of
stylus).
0 Can cause scratches or noise.
0 Can cause howling.
0 Can cause hum, noise.
0 May cause corrosion of the front panel.
