Page 1

2 1 23 4 1234 C D F A B E PDP-S41 1.REASSEMBLY AND DISASSEMBLY PRECAUTIONS The grille ASSY is attached to the baffle by its bosses and double-sided self-adhesive tape. To detach it, first remove the packing(SEC2098) on the top of the unit and packings(SEB1302) inserted between the baffle and the cabinet L(R). *Be careful not to damage the grille ASSY by bending too much. To re-attach it, first press it to the baffle using new double-sided self-adhesive tape. Grille ASSY BaffleGrille ASSY Baffle Next, insert packings(SEB1302) between the baffle and the cabinet L(R) . Then, attach new packing(SEC2098) on the top of the unit. Packing SEB1302Packing SEB1302 SPEAKER SYSTEM (BACK SIDE) Then pry it open little by little by inserting a flat blade screw- driver (covered with a cloth) into the slot between the grille ASSY and the baffle. Grille ASSY Cloth Screwdriver(-)Baffle Slot Grille ASSYPacking (SEC2098) Packing (SEC2098) Packing (SEC2098) (7)(7) (7)(7) Top View Grille ASSY Side View Tape (SEH1091) Tape (SEH1091)Tape (SEH1093) Tape (SEH1093) Baffle

Page 2

3 1 234 1 23 4 C D F A B E PDP-S41 The woofer(L) is attached to the baffle by 4 internal screws. To detach it, unfasten the 2 screws on the back of cabinet C. Then, unfasten the 11 screws on the front of cabinet C and 12 screws on the front of cabinet L. Do the same for the woofer(R). When attaching, the plus terminal should be facing inward. The tweeter is attached to the baffle by 2 internal screws. To detach it, unfasten the 2 screws on the back of cabinet C. Then, unfasten the 11 screws on the front of cabinet C and 12 screws on the front of cabinet L. Do the same for the woofer(R). When attaching, the plus terminal should be facing upward. It is hard-wired between the input terminal and the network ASSY. When detaching the Network ASSY, swing to pull it out. Network ASSY 1 2 1 Input terminal To re-attach them, fasten screws as follows. 1 2 3 4 5 6 7 10 12 13 11 8 14 15 9
