Page 1
2
1
23
4
1234
C
D
F
A
B
E
PDP-S40
Network ASSY
1 2
1
Input terminal
1.REASSEMBLY AND DISASSEMBLY PRECAUTIONS
The grille ASSY is attached to the baffle by its bosses and
double-sided self-adhesive tape.
To detach it, first remove the packing on the top of the unit.
Then pry it open little by little by inserting a flat blade screw-
driver (covered with a cloth) into the slot between the grille
ASSY and the baffle. The woofer is attached to the baffle by 4 internal screws.
To detach it, unfasten the 6 screws on the back of cabinet C.
Then, unfasten the 12 screws on the front of cabinet L. Do the
same for cabinet R.
When attaching, the plus terminal should be facing inward.
The tweeter is attached to the baffle by 2 internal screws.
To detach it, unfasten the 6 screws on the back of cabinet C.
Then, unfasten the 12 screws on the front of cabinet L. Do the
same for cabinet R.
When attaching, the plus terminal should be facing upward.
It is hard-wired between the input terminal and the network
ASSY. When detaching the Network ASSY, swing to pull it
out.
Grille ASSY
Cloth
Screwdriver(-)Baffle
Slot
*Be careful not to damage the grille ASSY by bending too much.
To re-attach it, press it to the baffle using new double-sided
self-adhesive tape.
Grille ASSY
Baffle
Grille ASSY
Baffle
Then, attach new packing on the top of the unit.
Grille ASSYBaffle
Packing
Tape
SEH1089
Baffle
Page 2
3
1
234
1
23
4
C
D
F
A
B
E
PDP-S40
1
25
27 26
29 19
33
33 7
1328
32 32
24 24
31
3
5 2
4
6
8
12
10
11 9
14
18
1516
17
2023
22
21
34
373635
30
2.EXPLODED VIEW
2.1 PACKING
PACKING PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation. NOTES:
Mark No. Description Part No. Mark No. Description Part No.
NSP 1 Accessory Set SME3695
2 Speaker Wire SDS1191
3 Polyethylene Bag S1 SHL1439
NSP 4 Screws Set SME3696
5 Screw BMZ50P100FTB
6 Polyethylene Bag S0 SHL1438
7 Bracket Assy(L) SXG1107
NSP 8 Label(L) SAK1024
9 Gasket SED1136
10 Gasket(L) SED1137
11 Gasket SED1138
NSP 12 Bracket L SNA1465
13 Bracket ASSY(R) SXG1108
NSP 14 Label(R) SAK1025
15 Gasket SED1136
16 Gasket SED1138
17 Gasket(R) SED1139
NSP 18 Bracket R SNA1466
19 Bracket ASSY(C) SXG1109
20 Gasket SED1140
21 Gasket SED1141
22 Gasket SED1142
NSP 23 Bracket C SNA146724 Form Pad(Side) SHA2544
25 Form Pad(C-T) SHA2545
26 Form Pad(C-M) SHA2546
27 Form Pad(C-B) SHA2547
28 Protection Sheet S3 SHC1846
29 Protection Sheet S1 SHC1847
30 Spaser SHD1072
31 Packing Case (for XTW/E5)SHG2745
31 Packing Case (for XTW/CN5)SHG2746
32 Packing Bag S2 SHL1450
33 Polyethylene Bag S0 SHL1451
NSP 34 CS ASSY (for XTW/E5)SMW1947
NSP 34 CS ASSY (for XTW/CN5)SMW1948
NSP Label Serial SRW1112
for XTW/E5 type
NSP 35 Inst. Manual Set SME3733
36 Polyethylene bag s2 SHL1437
37 Operating Instructions SRD1325
(English, French, German,
Italian, Dutch, Spanish, Chinese)
for XTW/CN5 type
NSP 35 Inst. Manual Set SME3737
36 Polyethylene bag s2 SHL1437
37 Operating Instructions SRD1326
(Chinese)
