PDP-S31-LR
FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY
The grille is attached to the baffle using double-sided self-adhe-
sive tape. To avoid damaging the grille, work with the speaker
on top of a blanket or similar, face up.
There are two slots in the lower part of the speaker. Insert a
screwdriver(-) into each slot and push down detach the lower
part.
Turn the speaker over and insert a screwdriver(-) between the
grille and the baffle. Taking care not to damage the baffle, push
down on the screwdriver(-) to prize the baffle and grille apart.
When reattaching the grille, use double-sided self-adhesive
tape in the locations shown in the diagram and press the grille
assy into place.
The grille is fixed using boss and double-sided self-adhesive
tape(The tape is in the locations indicated in the diagram be-
low). Do not use a dryer to heat the self-adhesive tape when
removing the grille.
The woofer is attached to the baffle by external screws. To de-
tach it, unfasten those screws. When attaching it, face its termi-
nal downward.
The tweeter is attached to the baffle by external screws. To de-
tach it, unfasten those screws.
Slot
GRILLE
Screwdriver(-)
Grille
BaffleDown
LOCATIONS TO FIX DOUBLE-SIDED
SELF-ADHESIVE TAPE
Tape
(SEH1057 x2)
Page 2
3
1
234
1
23
4
C
D
F
A
B
E
PDP-S31-LR
Mark No. Description Part No.
NSP Baffle SNK2785
NSP Cabinet SNK2787
Grille ASSY SMG1821
NSP Grille Cloth SAS1575
NSP Grille Frame SMH1088
NSP Cosmetic Frame SNK2789
Network ASSY SWN1736
Capacitor 2.7 SCE1029
NSP Packing SEB1232
NSP Gasket SEC1855
NSP Gasket SEC1856
NSP Gasket SEC1857
NSP Gasket SEC1860
NSP Terminal SFK1034
NSP Terminal SFK1035
Choke coil 1.1 STH1260
NSP Rosin core solderpbf ZSA-5020-1R6
NSP Red-Black wire ZWWAC3318-20
NSP Red-White wire ZWWAC3318-29
NSP Blue-White wire ZWWAC3318-69
Input Terminal KKX1015
NSP Model Label (L) SAN3551
NSP Model Label (R) SAN3552
NSP Insert Nut M5 SBN1056
NSP Gasket (BF:WF-TW) SEB1250
NSP Gasket (Input-Side) SEB1255
NSP Gasket (WF:Input) SEB1256
NSP Gasket (TW:Input) SEB1271
NSP Gasket (BF:C) SEB1272
NSP Gasket (CAB:Input) SEB1273
Gasket (Input Terminal Back) SEC1724
NSP Gasket (WF:Gasket) SEC1754
NSP Gasket (CAB:Short) SEC1859
NSP Gasket (BF-CAB:Long) SEC1868
NSP Gasket (BF:Outside) SEC1869
NSP Gasket (CB:TW Side) SEC1878
NSP Felt (CB:Input C UN) SED1113
NSP Felt (Duct Inside) SED1122
Tape (Grille ASSY) SEH1057
NSP Paper Tube 26 SMR1380
NSP Port Tube Ring 26 SMR1382
NSP Acoustic Absorbent (Roll :Small) SMT1240
NSP Acoustic Absorbent (CAB:Roll) SMT1246
NSP Acoustic Absorbent (BF:U UN) SMT1248
NSP Acoustic Absorbent (CB:UN) SMT1249
NSP Acoustic Absorbent (Duct Outside) SMT1250
NSP Acoustic Absorbent (CAB:Roll) SMV2183
NSP Acoustic Absorbent (CB:L Side) SMV2205
NSP Acoustic Absorbent (Roll :Small) SMV2206
Spacer ASSY SMX1100
NSP Gasket SEC1877
NSP Tape SEH1063
NSP Spacer SNK2824
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation. NOTES:
PARTS LIST
Mark No. Description Part No.
Spacer ASSY SMX1101
NSP Gasket SEC1879
NSP Tape SEH1064
NSP Spacer SNK2825
NSP Label Serial (Model Label L,R) SRW1083
Speaker A101EC65-54F
Speaker FADD55-52F
NSP Accessorys Set SME3516
Protection Sheet S1 SHC1815
Spacer SHD1060
Spacer SHD1061
Accessory Case SHF1086
Bracket A ASSY (R) SNX1167
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket SEC1862
Spacer SEP1315
NSP Bracket A SNA1433
NSP Clear tape 12mm ZTA-400-12
Bracket A ASSY (L) SNX1168
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket SEC1862
Spacer SEP1315
NSP Bracket A SNA1433
NSP Clear tape 12mm ZTA-400-12
Bracket B ASSY (R) SNX1169
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket SEC1862
Spacer SEP1315
NSP Bracket B SNA1434
NSP Clear tape 12mm ZTA-400-12
Bracket B ASSY (L) SNX1170
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket SEC1862
Spacer SEP1315
NSP Bracket B SNA1434
NSP Clear tape 12mm ZTA-400-12
NSP Danpron tape ZTA-Danpron-50cl
NSP Accessory Set SME3527
NSP Polyethylene Bag S1 KHL1079
NSP Screws Set SME3510
Screw BMZ50P100FZK
NSP Polyethylene Bag S0 KHL1081
NSP Max no.10-1m ZMX-MAX10-1M
Speaker Wire Set SME3528
Speaker Wire SDS1167
NSP Polyethylene Bag S1 SHL1359
NSP Max no.10-1m ZMX-MAX10-1M
NSP Max no.10-1m ZMX-MAX10-1M
