COMPACT DISC PLAYER

D-4DED

PD-4DED-S

:3

371.3

MODEL ID-4050 AND PD4050-S COMES IN SEVEN VERSIONS DISTINGUISHED AS FOLLOWS:

Applicable model
Type Power requirement Excom destination
ID-4050 PD-4050-S
KU O - AC1 20V only U.S.A.
KC 0 - ACIZOV only Canada
HEM O O AC220V. 240V (swiIchabIe) ' European cominent
HP 0 - AC220V, 240V (switchable) Australia
SD 0 - AC1 10V, 120-127V, 220V, 240V (switchable) General market
80/6 0 - ACI 10V, 120-127V, 220V, 240V (swixchable) U.S. Miliiary
HE D O AC220V, 240V (switchable) United Kingdom

A" Change the positIDn of jumper DI the Transformer beard assembly.
This service manual is applicable to the KU, KC, HEM, HB, HP, SD and 80/6 types.
As to the KC, HEM, HB, HP, SI? and SD/G types, please refer to pages 75.
Ce manuel dinstruction se refére au mode de réglage en frangais.
Este manual de servicio trata del método ajuste escrito en espafiol.

CONTENTS

I. SAFETY INFORMATION ............... 2 9. ELECTRICAL PARTS LIST .............. 33
2. SPECIFICATIONS ..................... 4 IO. ADJUSTMENTS ...................... 36
3. PANEL FACILITIES ................... 5 REGLAGE .......................... 49
4. DISASSEMBLY ....................... 9 ADJUSTE ........................... 62
5. EXPLODED VIEWS AND PARTS LIST ..... 13 11. FOR KC, HEM, HB, HP,

6. PACKING ........................... 18 SD AND SD/G TYPES ................. 75
7. P.C. BOARDS CONNECTION DIAGRAM 21

a. SCHEMATIC DIAGRAM ................ 28

PIONEER ELECTRONIC CORPORATION 4-I. Meguro 1-Chome, Meguro-ku. Tokyo 153. Japan

PIONEER ELECTRONICS SERVICE INC. PO. Box 1760, Long Beach, CalilomIa 90801 U S.A.

PIONEER ELECTRONICS OF CANADA INC 505 Cochrane Dnve. Markham Ontano L3H 688 Canada TEL: [416] 479.4411
PIONEER ELECTRONIC [EUROPE] N V. Keelberglaan 1.2740 Beveren. BeIqum TEL 03/775 28 08

PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178 184 Boundary Road. BraeSIde. VIcIona 3195 Austraha TEL. (033 580 9911

MI (9 MAR. 1987 Printed in Japan
