Extracted text from pioneer kehp 6010 service manual (Ocr-read)
Page 1
2
KEH-P601,P6010
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
4
7
11310
98
6
5
16
217
1215
14
131
18
19
20
21
22
1. SAFETY INFORMATION
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
W
ARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
Page 2
3
KEH-P601,P6010
1-1 Polyethylene Bag CEG1116
1-2 Owners Manual(P601) CRD3342
Owners Manual(P6010) CRD3341
1-3 Installation Manual(P601) CRD3347
Installation Manual
(P6010) CRD3346
* 1-4 Warranty Card(P601) CRY1070
* 1-5 Caution Card(P601) CRP1242
2 Cord Assy CDE6436
3 Spring CBH1650
4 Screw Assy CEA2796
5 Screw CBA1002
* 6 Polyethylene Bag CEG-127
7 Screw CRZ50P090FMC
8 Screw TRZ50P080FMC
9 Polyethylene Bag CEG-15810 Handle CNC5395
11 Bush CNV3930
12 Polyethylene Bag CEG1173
13 Carton(P601) CHG4206
Carton(P6010) CHG4205
14 Contain Box(P601) CHL4206
Contain Box(P6010) CHL4205
15 Protector CHP2243
16 Protector CHP2244
17 Case Assy CXB3520
18 Screw BPZ20P060FZK
19 Remote Control Unit CXB6796
20 Battery CEX1065
21 Accessory Assy CEA2773
22 Earth Plate CNC9450 Mark No. Description Part No. Mark No. Description Part No.
-PACKING SECTION PARTS LIST NOTE:
-Parts marked by * are generally unavailable because they are not in our Master Spare Parts List.
-Screws adjacent to -ˆ‡mark on the product are used for disassembly.
-Owner's Manual, Installation Manual
Model Part No. Language
KEH-P601/X1M/UC CRD3342,CRD3341 English, French
KEH-P6010/X1M/UC CRD3347,CRD3346 English, French
