DEH-P720,P7200
-CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer
to"Disassembly"(see page 56).
During replacement, handling precautions shall be
taken to prevent an electrostatic discharge(protection
by a short pin).2. During disassembly, be sure to turn the power off
since an internal IC might be destroyed when a con-
nector is plugged or unplugged.
3. Please checking the grating after changing the ser-
vice pickup unit(see page 49).
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
W
ARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
1. SAFETY INFORMATION
19
18
15
13
17
16
5 8
12411
109
7
6
3
1
2
14 20
Page 2
3
DEH-P720,P7200
1 Carton(P720) CHG4009
Carton(P7200) CHG4008
2 Cord Assy(P720) CDE6241
Cord Assy(P7200) CDE6291
* 3 Accessory Assy CEA2395
4 Spring CBH1650
* 5 Screw Assy CEA2396
6 Screw CBA1002
* 7 Polyethylene Bag CEG-127
8 Screw CRZ50P090FMC
9 Screw TRZ50P080FMC
* 10 Polyethylene Bag CEG-158
11 Handle CNC5395
12 Bush CNV3930
13 Polyethylene Bag CEG117314 Battery(P720) CEX1006
15 Contain Box(P720) CHL4009
Contain Box(P7200) CHL4008
16 Protector CHP2251
17 Protector CHP2252
18 Case Assy CXB3520
19-1 Polyethylene Bag CEG1116
19-2 Owners Manual(P720) CRD3172
Owners Manual(P7200) CRD3174
19-3 Installation Manual(P720) CRD3173
Installation Manual
(P7200) CRD3175
* 19-4 Warranty Card CRY1070
* 19-5 Card(P7200) ARY1048
* 19-6 Warranty Card CRP1207
20
Remote Control Assy(P720) CXB4285 Mark No. Description Part No. Mark No. Description Part No.
-PACKING SECTION PARTS LIST NOTE:
-Parts marked by * are generally unavailable because they are not in our Master Spare Parts List.
-Screws adjacent to
Ñmark on the product are used for disassembly.
-Owner's Manual, Installation Manual
Model Part No. Language
DEH-P720/X1N/UC CRD3172 English, French
CRD3173 English, French
DEH-P7200/X1N/UC CRD3174 English, French
CRD3175 English, French
