Page 1
2
DEH-P400,P4000,P4050
-CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer
to"Disassembly"(CX-916 Service Manual CRT2300).
During replacement, handling precautions shall be
taken to prevent an electrostatic discharge(protection
by a short pin).2. During disassembly, be sure to turn the power off
since an internal IC might be destroyed when a con-
nector is plugged or unplugged.
3. Please checking the grating after changing the ser-
vice pickup unit(see page 55).
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
W
ARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
1. SAFETY INFORMATION
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
20
19
15
12
16
17
4 7
11310
98
6
5
2
14
18
13
1
Page 2
-Owners Manual
Model Part No. Language
DEH-P400/X1N/UC CRD2822 English, French
DEH-P4000/X1N/UC CRD2820 English, French
DEH-P4050/X1N/ES CRD2832 English, Spanish, Portuguese
CRD2833 Arabic, Chinese
-Installation Manual
Model Part No. Language
DEH-P400/X1N/UC CRD2823 English, French
DEH-P4000/X1N/UC CRD2821 English, French
DEH-P4050/X1N/ES CRD2834 English, Spanish, Portuguese, Arabic, Chinese
3
DEH-P400,P4000,P4050
1 Cord Assy CDE5769
* 2 Accessory Assy CEA2395
3 Spring CBH1650
4 Screw Assy CEA2396
5 Screw CBA1002
* 6 Polyethylene Bag CEG-127
7 Screw CRZ50P090FMC
8 Screw TRZ50P080FMC
* 9 Polyethylene Bag CEG-158
10 Handle CNC5395
11 Bush CNV3930
12 Polyethylene Bag
See Contrast table(2)
13 Battery CEX1030
14 Carton
See Contrast table(2)
15 Contain Box See Contrast table(2)
16 Protector CHP2101
17 Protector CHP2102
18 Remote Control Unit CXB3455
19 Case Assy CXB3520
20-1 Owners Manual
See Contrast table(2)
20-2 Owners Manual See Contrast table(2)
20-3 Installation Manual See Contrast table(2)
* 20-4 Warranty Card See Contrast table(2)
20-5 Polyethylene Bag CEG1116
* 20-6 Card
See Contrast table(2)
* 20-7 Label See Contrast table(2)
Mark No. Description Part No. Mark No. Description Part No.
(1) PACKING SECTION PARTS LIST NOTE:
-Parts marked by * are generally unavailable because they are not in our Master Spare Parts List.
-Screws adjacent to Ñmark on the product are used for disassembly.
Part No. Mark No.Symbol and Description DEH-P400/X1N/UC DEH-P4000/X1N/UC DEH-P4050/X1N/ES
12 Polyethylene Bag CEG1173 CEG1173 CEG-162
14 Carton CHG3642 CHG3641 CHG3643
15 Contain Box CHL3642 CHL3641 CHL3643
20-1 Owners Manual CRD2822 CRD2820 CRD2832
20-2 Owners Manual Not used Not used CRD2833
20-3 Installation Manual CRD2823 CRD2821 CRD2834
* 20-4 Warranty Card CRY1070 Not used Not used
* 20-6 Card Not used ARY1048 Not used
* 20-7 Label CRW1343 CRW1343 Not used
(2) CONTRAST TABLE
DEH-P400/X1N/UC, DEH-P4000/X1N/UC and DEH-P4050/X1N/ES are constructed the same except for the
following:
