C0 NTE NTS
Line Voltage and Rear Panels ............ 2 Recording via Microphones ............. 12
Features ............................ 3 Other Recording Techniques ............ 12
Installation Cautions .................. 3 Playback Steps ....................... 13
Front Panel Facilities ................. 4 Employing Dolby System ............... 14
Connection Diagram ................... 6 Maintenance ------------ 15
Cassette Tapes ........................ '7 Specifications .................... Insertion
Basic Operation ...................... 8 Trouble? Please Check ............. Insertion
Recording Steps ...................... 10 Schematic Diagram ................ Insertion

LINE VOLTAGE AND REAR PANELS

CT-F7070 are designed to accept different line
voltages, according to the country in which they
are to be used, although the operation of the
various models is the same in every respect. Fig. A
shows the model designed to operate at any of two
pre-selected Voltages (220V, 240V).

Fig. B shows the model designed to operate at any
of three selected voltages (120V, 220V, 240V).
Line voltage and fuse can be changed and set as
follows:

220V and 240V MODEL

Changing line voltage setting (Fig. C)

1. Disconnect the A.C. mains cord.

2. Use a Phillips screwdriver to take out the FUSE
CAP and fuse.

3. Pull out the VOLTAGE SELECTOR plug from
the socket.

4. Put the selector plug back so that the appro-
priate line voltage marking can be seen through
the cut in the edge of the plug.

5. Replace the fuse and FUSE CAP.

120V, 220V and 240V MODEL

Changing line voltage and fuse setting (Fig. C)

1. Disconnect the AC. mains cord.

2. Use a Phillips screwdriver to take out the FUSE
CAP and fuse.

3. Pull out the VOLTAGE SELECTOR plug from
the socket.

4. Put the selector plug back so that the appro-
priate line voltage marking can be seen through
the cut in the edge of the plug.

5. Change the fuse in accordance with the table.

6. Replace the fuse and FUSE CAP.

220V. 240V model Rear Panel

Fig. A

120V, 220V, 240V model Rear Panel

Fig. C

PHILLIPS SOCKE
scnswonlven T

FUSE PLUG
" FUSE

FUSE CAP
TABLE?! _
VOLTAGE F USE

120V 1A
220v '-
24ov A
