Pioneer csa 500 service manual

This is the 9 pages manual for pioneer csa 500 service manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 9
left right
pioneer csa 500 service manual

Extracted text from pioneer csa 500 service manual (Ocr-read)


Page 1

cs-A=ioo 1. SPEC IFICATIONS Enclosure: Speakers: Woofer Mid range Tweeter lnput impedance: Frequency range: Sensitivity: Maximum inputpower: Crossover frequency: Lows. .. Midranges 800H2 Midranges ..... Highs 6,000H2, (ln case multi-channel amplifiers are used) 2-channel amplif iers: Lows . . Mid ranges and Highs 500 to 1,000H2 3-channel amplifiers: Lows . . . Mid ranges 500 to 1,000H2 Mid ranges ..... Highs 4,000to6,000H2 External dimensions: 570(H) x 330(W) x 320(D)mm 22 7116"Hl x 13"(W) x 12 19132"(Dl Weight: 14.5k9 (31 lb 14 oz) NOTE: Specifications and the design subject to possible modification without notice due to improvements. /lNcRE/4Sl I LISTENIre W/' d0RflAL ^A TDECREASE Vq ./ r/ ^rso' w 204 500 t000 2000 FREQUENCY I N HZ Totally enclosed type 10"(25cm) cone type 5"(12cm) cone type 3"(7.7cml cone type 8 ohms 40 to 20,000H2 94dB/W at 1m distance 50w ,a S rooz- 90 u 3eo& H"o 6A o t00 zgo4280du70E 60 q 1tou d lo z 200 500 1M0 2M FREQUENCY lN Hz 40 2A0 5m 1000 2004 FREQUENCY iN Az ^t lt \ v'{ \:,r'{:% f,vi V v'\'

Page 2

2.REPLACEMENT OF SPEAKER UNIT I . lO"WOOFER a. Remove screws holding the speaker, and pull i( out gently toward you. (Photo 1) b. Pull the Blue and White speaker leads off from the speaker terminals. (Photo 2) c. Mounting of NEW speaker. Push the Blue lead end onto the Red terminal. Mount the NEW speaker onto the baffle board. Screw speaker tightly onto the baffle board. II. 5''MID-RANGE a. Remove screws holding the speaker, and pull it out gently toward you. b. Pull the Green and White leads off from the speaker terminals c. Mounting NEW speaker. Push the Green lead female end onto the Red side male end of the speaker terminal. T'hen, mount the NEW speaker onto the front baffle board. Screw the speaker tightly onto the baffle board. il . 3''TWEETER a. Remove screws holding the speaker, and pull it out gently toward you. b. Pull the Red and White leads off from the speaker terminals. c. Mounting of NEW speaker. Push the Red lead female end onto the Red side male end of the speaker, and push the White lead female end onto the other male end of the same speaker terminal. Then, mount the NEW speaker onto the baffle board. Screw speaker tightly onto the baffle baord. N. CARE TAKEN TO REPLACE A The speakers of low, middle, and high ranges are of the cone type; hence, if their cone or cap should become damaged, the tone quality will be affected significantly. Therefore, carefulness should be used while removal from cabinet and, again, installed in the cabinet. Viewing it from the back side terminal are always io identify the bottom side of the speaker, the positive terminal (Red side) is always to the right side of the speaker and the negative terminal is always to the left side of the speaker. Photo 1 o SPEAKER b. Photo 2
