Thank youfor buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Be sure to read this
! Playable discs 5
! DVD video disc region numbers 6
! When an operation is prohibited 10
Precautions
IMPORTANT SAFEGUARDS3
To ensure safe driving 3
To avoid battery exhaustion 4
Before You Start
Information to User5
For Canadian model 5
About this unit 5
About this manual 6
After sales service for Pioneer products 6
Visit our website 7
Features 7
About WMA 8
About the SAT RADIO READY mark 9
To protect the LCD screen 9
For viewing LCD comfortably 9
What the marks on DVDs indicate 9
Protecting your unit from theft 10
Resetting the microprocessor 10
Operating this unit
Whats What 12
Basic Operations 13
Tuner 18
Built in DVD player 20
Audio Adjustments 30
Setting up the DVD player 35
Initial Settings 38
Other Functions 41
Available accessories
XM tuner45
SIRIUS Satellite Radio tuner 47
Playing songs on iPod 49
Multi CD Player 51
DVD Player 54
TV tuner 56
Digital Signal Processor 58
Additional Information
Troubleshooting70
Error messages 72
Understanding auto TA and EQ error messages 72
Understanding messages 73
Handling guideline of discs and player 74
DVD discs 74
CD R/CD RW discs 74
Dual Discs 75
Compressed audio files on the disc 75
Using the display correctly 76
Language code chart for DVD 78
Terms 79
Specifications 82
Index 84
Contents
En 2
Page 2
IMPORTANT SAFEGUARDS
Please read all of these instructions regarding
your display and retain them for future refer
ence.
1Read this manual fully and carefully be-
fore operating your display.
2 Keep this manual handy as a reference for
operating procedures and safety informa-
tion.
3 Pay close attention to all warnings in this
manual and follow the instructions care-
fully.
4 Do not allow other persons to use this sys-
tem until they have read and understood
the operating instructions.
5 Do not install the display where it may (i)
obstruct the driver s vision, (ii) impair the
performance of any of the vehicle s oper-
ating systems or safety features, includ-
ing air bags, hazard lamp buttons or (iii)
impair the driver s ability to safely oper-
ate the vehicle.
6 Do not operate this display if doing so in
any way will divert your attention from
the safe operation of your vehicle. Always
observe safe driving rules and follow all
existing traffic regulations. If you experi-
ence difficulty in operating the system or
reading the display, park your vehicle in a
safe location and make necessary adjust-
ments.
7 Please remember to wear your seat belt at
all times while operating your vehicle. If
you are ever in an accident, your injuries
can be considerably more severe if your
seat belt is not properly buckled.
8 Never use headphones while driving.
9 To promote safety, certain functions are
disabled unless the parking brake is on,
and the vehicle is not in motion.
10 Never set the volume of your display so
high that you cannot hear outside traffic
and emergency vehicles.
WARNING !Do not attempt to install or service your
display by yourself. Installation or servi-
cing of the display by persons without
training and experience in electronic
equipment and automotive accessories
may be dangerous and could expose you
to the risk of electric shock or other
hazards.
To ensure safe driving
WARNING !LIGHT GREEN LEAD AT POWER CON-
NECTOR IS DESIGNED TO DETECT
PARKED STATUS AND MUST BE CON-
NECTED TO THE POWER SUPPLY SIDE
OF THE PARKING BRAKE SWITCH. IM-
PROPER CONNECTION OR USE OF
THIS LEAD MAY VIOLATE APPLICABLE
LAW AND MAY RESULT IN SERIOUS IN-
JURY OR DAMAGE.
! To avoid the risk of damage and injury and the
potential violation of applicable laws, this unit
is not for use with a video screen that is visible
to the driver.
! To avoid the risk of accident and the potential
violation of applicable laws, the front DVD or
TV (sold separately) feature should never be
used while the vehicle is being driven. Also,
rear displays should not be in a location
where it is a visible distraction to the driver.
! In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed and this unit s DVD features should
not be used.
Precautions
En 3
Section
01
Precautions
