Page 1
Thank youfor purchasing this PIONEER product.
Please read through this manual before using the product for the first time, to en-
sure proper use. After reading, please keep the manual in a safe and accessible place
for future reference.
Be sure to read this
! DVD video disc region numbers 7
! When an operation is prohibited 10
! Handling guideline of discs and player 99
Precautions
IMPORTANT SAFEGUARDS5
To ensure safe driving 5
To avoid battery exhaustion 6
Before You Start
Information to User7
For Canadian model 7
About this unit 7
About this manual 7
After sales service for Pioneer products 8
Visit our website 8
Features 8
When an operation is prohibited 10
Resetting the microprocessor 10
Feature demo mode 10
Whats what
Head unit 11
Optional remote control 11
Basic Operations
Power ON/OFF12
Selecting a source 12
Adjusting the volume 13
Touch panel key basic operation 13
Adjusting the LCD panel angle 15
Built in DVD player basic operations 15
Radio
Listening to the radio17
Storing and recalling broadcast frequencies 17
Introduction of advanced tuner operation 18 Storing the strongest broadcast
frequencies 18
Tuning in strong signals 18
Playing DVD discs
Watching a DVD19
Skipping back or forward to another title 20
Operating the DVD menu 20
Resume playback (Bookmark) 20
CM skip/CM back 20
Frame by frame playback 21
Slow motion playback 21
Pausing playback 21
Searching for the part you want to play 21
Changing audio language during playback
(Multi audio) 21
Changing the subtitle language during playback (Multi subtitle) 22
Changing the viewing angle during playback
(Multi angle) 22
Return to the specified scene 22
Automatic playback of DVDs 22
Introduction of advanced DVD operation 23
Repeating play 23
Selecting audio output 23
Playing Video CDs
Watching a Video CD24
PBC playback 24
Frame by frame playback 25
Slow motion playback 25
Pausing playback 25
Searching for a desired scene, starting playback from a specified time 25
Introduction of advanced Video CD operation 25
Repeating play 26
Selecting audio output 26
Playing CDs
Listening to a CD27
Selecting tracks from the track title list 27
Contents
En 2
Page 2
Pausing playback27
Switching the media file type 28
Using advanced sound retriever 28
Introduction of advanced CD operation 28
Repeating play 28
Playing tracks in random order 28
Scanning tracks of a CD 28
Playing compressed audio
Listening to compressed audio 29
Selecting files from the file name list 30
Pausing playback 30
Switching the media file type 30
Using advanced sound retriever 30
Introduction of advanced compressed audio
operation 30
Repeating play 31
Playing tracks in random order 31
Scanning folders and tracks 31
Playing DivX/JPEG files
Watching a DivX/JPEG32
Viewing a JPEG slideshow 33
Playing DivX® VOD content 33
Selecting files from the file name list 33
Displaying text information on DivX/JPEG disc 34
Pausing playback 34
Switching the media file type 34
Searching for the part you want to play 34
Changing audio language during playback (Multi audio) 34
Changing the subtitle language during playback (Multi subtitle) 34
Capture an image in JPEG files 34
Introduction of advanced DivX/JPEG
operation 35
Repeating play 35
Playing files in random order 35
Playing songs in a USB storage device
Basic Operations36 Selecting files from the file name list
36
Pausing compressed audio playback 37
Switching the media file type 37
Using advanced sound retriever 37
Introduction to advanced operations 37
Using iPod
Basic Operations38
Playing video 39
Browsing for a song/video 39
Displaying text information on iPod
Video 40
Pausing a song 40
Using advanced sound retriever 40
Repeating play 40
Playing songs/videos in a random order (shuffle) 40
Playing all songs in a random order (shuffle all) 41
Operating this unit s iPod function from your
iPod 41
Selecting songs from lists related to the
currently playing song 41
Changing audiobook speed 41
Changing the screen mode 41
Audio Adjustments
Introduction of audio adjustments 42
Using balance adjustment 42
Using the equalizer 42
Adjusting loudness 43
Using subwoofer output 43
Boosting the bass 43
Using the high pass filter 44
Adjusting source levels 44
Setting up the DVD player
Introduction of DVD setup adjustments 45
Setting the subtitle language 45
Setting the audio language 45
Setting the menu language 46
Setting the angle icon display 46
En 3
Contents
