A-209R, A-209
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause
cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 Ð Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODéLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que les pices
de remplacement doivent avoir la mme dŽsignation.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the protection
afforded by them necessarily can be obtained by using
replacement components rated for voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this Service Manual.
Electrical components having such features are identified
by marking with a
on the schematics and on the parts list
in this Service Manual.
The use of a substitute replacement component which does
not have the same safety characteristics as the PIONEER
recommended replacement one, shown in the parts list in
this Service Manual, may create shock, fire, or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Service
Manual. A subscription to, or additional copies of, PIONEER
Service Manual may be obtained at a nominal charge from
PIONEER.
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 229-2 or equivalent between the
earth ground and all exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, control
shaft, etc.). Plug the AC line cord of the appliance directly
into a 120V AC 60Hz outlet and turn the AC power switch
on. Any current measured must not exceed 0.5mA.
(FOR USA MODEL ONLY)
Leakage
current
testerReading should
not be above
0.5mA
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)Earth
ground
AC Leakage Test
Page 2
3
A-209R, A-209
2.1 PACKING
Mark No. Description Part No.
2. EXPLODED VIEWS AND PARTS LIST
NOTES: · Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
· The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
· Screws adjacent to mark on the product are used for disassembly.
1 Operating Instructions See Contrast table(2)
(English)
2 Operating Instructions See Contrast table(2)
(German)
3 Operating Instructions See Contrast table(2)
(French/Italian/Dutch/Swedish/Spanish/Portugese)
NSP 4 Warranty Card See Contrast table(2)
5 Remote Control Unit (CU-A019) See Contrast table(2)
6 Battery Cover See Contrast table(2)
NSP 7 Dry Cell Battery (AA/R6P) See Contrast table(2)
8 Side Pad L AHA7205
9 Side Pad R AHA7206
10 Sub Pad AHA7218
11 Packing Case See Contrast table(2)
NSP 12 Literature Bag AHG1180
13 Packing Sheet AHG7015
14 Operating Instructions See Contrast table(2)
(English/Spanish/Chinese)
15 Caution Label 220V See Contrast table(2)
16 AC Plug Adapter See Contrast table(2)
NSP 17 Air Cap See Contrast table(2)
18 Power Cord See Contrast table(2)
19 Power Cord with Fuse See Contrast table(2)
20 Fuse (T5A) See Contrast table(2)
(1) PACKING PARTS LIST
(2) CONTRAST TABLE
A-209R/MYXJ, MVXJ, A-209/MLXJ and SBDXJ are constructed the same except for the following :
6 12
17 20
19
13
8
10
11
9
5
7 18
MVXJ type Only
Except
MVXJ type
2 (MYXJ type
Only)15
(SBDXJ type
Only)
3 (MYXJ type
Only)
14 (MLXJ and
SBDXJ types
Only) 16 (SBDXJ
type Only)
1 (MYXJ and
MVXJ types
Only)
4 (MYXJ and
MVXJ types
Only)
FRONT
Part No.
Mark No. Symbol and Description A-209R A-209R A-209 A-209 Remarks
/MYXJ /MVXJ /MLXJ /SBDXJ
1 Operating Instructions (English) ARB7236 ARB7236 Not used Not used
2 Operating Instructions (German) ARC7322 Not used Not used Not used
3 Operating Instructions (French/Italian/ ARC7323 Not used Not used Not used
Dutch/Swedish/Spanish/Portuguese)
NSP 4 Warranty Card ARY7022 ARY7022 Not used Not used
5 Remote Control Unit (CU-A019) AXD7193 AXD7193 Not used Not used
6 Battery Cover AZN2249 AZN2249 Not used Not used
NSP 7 Dry Cell Battery (AA/R6P) VEM-013 VEM-013 Not used Not used
11 Packing Case AHD7869 AHD7869 AHD7870 AHD7891
14 Operating Instructions Not used Not used ARE7269 ARE7269
(English/Spanish/Chinese)
15 Caution Label 220V Not used Not used Not used ARR1003
16 AC Plug Adapter Not used Not used Not used VKX1007
NSP 17 Air Cap Not used AHG1087 Not used Not used
18 Power Cord ADG1154 Not used ADG1154 ADG115419 Power Cord with Fuse Not used ADG1156 Not used Not used
20 Fuse (T5A) Not used AEK1046 Not used Not used
