Page 1
1-2
LOCATION OF PC BOARDS
SPECIFICATIONS
SUBWOOFER
Subwoofer (not ma gnetically shielded desi gn).....................................................................\
............. .
......... ............6.5"
Output Powe r........................................................................\
.......................................... ...... ............ .......40W (4 -„¦ ,D IN)
THD ( Total Harmoni c Distortion) ...........................................................\
.................................. .......... ......10% at 55Hz
Reproduction Fre quency Response..........................................................\
..................................... .
... .......37Hz-145 Hz
Phase Switch............................................................\
...................................................... ............ ...................... 0
0
, 18 0 0
Input Sensitivity (Subwoofer In).....................................................................\
......................... .
............ ....... ....460 m Vrms
AC Power ...............................................................\
.......................................................... .....220 - 240V / 50 - 60 Hz
P ower Consumption........................................................\
.............................................. ....32 W (at 1/8 Rated Power)
Dimensions (w x h x d)................................................\
................................... ............ ......200 mm x 310mm x 350 mm
W ei ght......................................................................\
......................................... .......... ................. ......................6.5 Kg
