Page 2
1-3
SPECIFICATIONS
AMPLIFIER
Output power .................................... 4 x 75 W RMS*
Signal-to-noise ratio .......................... t 62 dBA (IEC)
Frequency response ......... 40 -“ 15000 Hz, ± 3 dB
Impedance loudspeakers ......................................... 4 :
Impedance headphones ........................................ 32 :
* (4 :, 1 kHz, 10% THD)
CD/MP3-CD PLAYER
Number of programmable tracks ......................... 20
Frequency range .................................. 20 -“ 20000 Hz
Signal-to-noise ratio ............................................ 75 dBA
Channel separation .......................... t 60 dB (1 kHz)
Total harmonic distor tion ................................. < 0.5%
MPEG 1 Layer 3 (MP3-CD) .......... MPEG AUDIO
MP3-CD bit rate ....................................... 32-256 kbps
(128 kbps advised)
Sampling frequencies ............ ...........32, 44.1, 48 kHz
USB PLAYER
USB ................................................................... 12Mb/s, V1.1 ......................................... suppor t MP3 and WMA files
Number of albums/folders ................. maximum 99
Number of tracks/titles ...................... maximum 500
TUNER
FM wave range ................................... 87.5 -“ 108 MHz
Sensitivity at 75 :
-“ mono, 26 dB signal-to-noise ratio ............ 2.8 µV
-“ stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Total harmonic distor tion ..................................... d 5%
Frequency response ..... 63 -“ 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... t 50 dBA TAPE DECK
Frequency response
Normal tape (type I) ...... 80 -“ 12500 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 50 dBA
Wow and flutter ......................................... d 0.4% DIN
SPEAKERS
System 2-way, double por t bass reflex
Woofer ................................................................... 1x13 cm
Tweeter ...................................................................... 1x5 cm
GENERAL INFORMATION
AC Power ....................... 110 -“ 240 V, 60Hz / 50 Hz
Standby Power Consumption........................ d 18 W
Dimensions (w x h x d)
-“ Main unit (w x h x d) ...... 175 x 252 x 360 mm
-“ Speaker box (w x h x d) 175 x 252 x 214 mm
Weight
With packing ......................................................... 10.16 kg
Main unit .................................................................... 3.18 kg
Speaker box ............................................................. 5.36 kg
Specifications and external appearance are
subject to change without notice.
