Page 1
PCBS LOCATION
FRONT BOARD
MAIN BOARD
CASS BOARD
1-2
Page 2
1-3
AMPLIFIER
Output power ........................................... 2 x 2W RMS
Signal-to-noise ratio .......................... t 60 dBA (IEC)
Frequency response ....................... 125 - 16000 Hz
Impedance loudspeakers ........................................... 8 :
CD PLAYER
Frequency range ............................... 125 - 16000 Hz
Signal-to-noise ratio ............................................ 65 dBA
TUNER
FM wave range ................................... 87.5 - 108 MHz
MW wave range ................................ 531 - 1602 kHz
Sensitivity
- FM 26 dB sensitivity .......................................... 20 Β΅V
- MW 26 dB sensitivity ................................... 5 mV/m
Total harmonic distor tion ..................................... d 5%
TAPE DECK
Frequency response
Normal tape (type I) ...... 125 - 8000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 40 dBA
Wow and flutter .............................................. d 0.4% JISSPEAKERS
Bass reflex system
Dimensions (w x h x d) . 134 x 230 x 152 (mm)
GENERAL INFORMATION
AC Power ............................ 110 - 127 / 220 - 240 V
....................................................... 50/60 Hz, switchable
Dimensions (w x h x d) .. 148 x 233 x 216 (mm)
Weight (with/without speaker s) ..................................
......................................................... approx. 3.65 / 1.53 kg
Power consumption
Active .......................................................................... 15 W
Standby .................................................................... < 4 W
Specifications and external appearance are
subject to change without notice.
SPECIFICATIONS
