SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable for /21/21M
120V for /37
220-230V for /22
Mains frequency : 50/60Hz
Power consumption : < 0.5W at ECO Power Standby
: <15W at Standby (DEMO mode off)
: 80W at Active
Clock accuracy : < 4 seconds per day
Dimension centre unit : 175 x 244 x 366mm
TUNER:
FM
Tuning range : 87.5-108MHz
Grid : 50kHz
100kHz for /37
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75-„¦ coaxial
300-„¦ click fit for /37
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 25dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHz for /21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.0mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
LW
Tuning range : 153-279kHz /22
Grid : 3kHz
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : [< 6.0mV/M]
Selectivity at 18kHz bandwidth : [> 24dB]
IF rejection : [> 45dB]
Image rejection : [> 30dB]
Distortion at RF=50mV, m=80% : [< 5%]AMPLIFIER:
Output power (6-„¦, 1kHz, 10% THD)
L & R : 2 x 50W RMS /21M/22
Output power (6-„¦, 60Hz-12.5kHz, 10% THD)
L & R : 2 x 40W FTC /37
Frequency response within -3dB : 50Hz-16kHz
Incredible Surround : ON/OFF
Treble : 12.5kHz ± 3 Steps
Bass : 55Hz ± 3 Steps
Woox : Level 1, 2, 3 & OFF
Input sensitivity
Aux in (at 1kHz) : 500mV ± 3dB at 600-„¦
CDR in (at 1kHz) : 1V ± 3dB at 600-„¦
Output sensitivity
Line out (Left/Right) : 500mV ± 3dB at 22k-„¦
Subwoofer out (50Hz - 8kHz) : 1.5V ± 3dB at 22k-„¦
Headphone output at 32-„¦: 680mV ± 1dB (Vol. Max.)
COMPACT DISC:
Measurement done directly at the connector on the board.
Output resistance : < 100-„¦
Output voltage (in Vrms) : 550mV ± 1dB (unloaded)
Frequency deviation : < 1%
Channel unbalance : < ±1dB
Frequency response : < ±1.5dB for 20Hz-20kHz
Signal to Noise Ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.02%
Crosstalk (1kHz) : >60dB
[....] Values indicated are for "ECO6 Cenelec Board" only.
