AMPLIFIER
Output powerL/R speaker s ............................. 25 W /channel RMS
Subwoofer ..................................................... 50 W RMS
Speaker channel Frequency Response .................................................................................................. 200 Hz - 18 kHz / ± 3 dB
Signal-to-Noise Ratio ...... > 60dB (A-weighted)
Input Sensitivity AUX In .................................................................. 500 mV
Output Sensitivity Line Out (1KHZ 0dB) ................................ 2 + 0.2V
TUNER
Tuning Range .............................. FM 87.5 -“ 108 MHz
Signal-to-Noise Ratio ................................ FM -‰¥ 50 dB
DV D
Laser Type ................................................ Semiconductor
Disc Diameter .............................................. 12cm / 8cm
Video Decoding ........................... MPEG-2 / MPEG-1
Video DAC ................................................................ 12 Bits
Signal System ............................................... PAL / NTSC
Video Format ..................................................... 4:3 / 16:9
Video S/N ........................................... 56 dB (minimum)
Composite Video Output ................ 1.0 Vp-p, 75 Ω
S-Video Output .......................... Y - 700 Vp-p, 75 Ω
.............................................................. C - 300 Vp-p, 75 Ω
Audio DAC .......................................... 24 Bits / 96 kHz
USB PLAYER
USB ................................................................. 12 Mb/s,V1.1 ......................................... suppor t MP3 and WMA files
Number of albums/folders ................. maximum 99
Number of tracks/titles ...................... maximum 800 Main unit
Power Supply Rating ................. 220 -240V / 50 Hz
Power Consumption
Active ........................................................................\
.. 60 W
Eco-power standby ............................................. <1 W
Dimensions (w x h x d) .... 232 x 85 x 275 (mm)
Weight ........................................................................\
... 1.24kg
Package Dimension (w x h x d) .................................. ...................................................... 615 x 515 x 225 (mm)
Gross weight. .................................................................. 4 kg
SPEAKERS
System ................................................... 1-way, Bass reflex
Impedance ........................................................................ 4 Ω
Speaker drivers .............................................. 3 fullrange
Frequency response ........................ 80 Hz -“ 20 kHz
Dimensions (w x h x d) . 160 x 250 x 180 (mm)
Weight ................................................................ 1.8 kg each
SUBWOOOFER
Impedance ........................................................................ 6 Ω
Speaker driver ..................................... 5.25 subwoofer
Frequency response .......................... 60HZ-1K HZ
Dimensions(w x h x d ) . 160 x 250 x 310 (mm)
Weight ........................................................................\
.... 7.4 kg
Specifications and external appearance are
subject to change without notice.
TECHNICAL SPECIFICATION
1 - 2
Type /Versions:
Features Board in used: MCD179
Service policy
DISPLAY BOARD
MAIN BOARD
TUENR BOARD
JACK BOARD
* TIPS : C -- Component Lever Repair. M -- Module Lever Repair
-- Used
/05 /12 /55 8
9
/
1
6
/
8
5
/
Feature diffrence
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK
C C
Type /Versions: MCD179
/05 /12 /55 8
9
/
1
6
/
8
5
/
M
C
VERSION VARIATION
C CM
C
