Page 1
1-1Service Tools:
Universal Torx driver holder .................................4822 395 91019
Torx bit T10 150mm ...........................................4822 395 50456
Torx driver set T6-T20 .........................................4822 395 50145
Torx driver T10 extended .....................................4822 395 50423Compact Disc:
SBC426/426A Test disc 5 + 5A ...........................4822 397 30096
SBC442 Audio Burn-in test disc 1kHz .................4822 397 30155
SBC429 Audio Signals disc .................................4822 397 30184
Dolby Pro-logic Test Disc ....................................4822 395 10216SERVICE AIDSGBWARNINGAll ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.ESDCLASS 1
LASER PRODUCTGBSafety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used
Safety components are marked by the symbol !.Lead free
Page 2
Set remains closed!
Standard repair procedureN
Y
Play a CD
for at least 10 minutes Yplayability
ok ?Nplayability
ok ?add Info for customer
"SET OK"playability
ok ?Y
N check playability N
Y playability
ok ?check playability
check playabilityEYE-Pattern
ok ?N
Y check "EYE-Pattern"
replace CD DriveLaser current
ok ?N
Y check Laser current
CD Drive offsetsok ?N Ycheck CD Drive offsetsclean the lens
check playabilityreturn set Customer complaint "CD related problem"return set
return setreplace CD Drivereturn setreplace CD Drivereturn setreplace Signal Processorreturn set"fast" lens cleaning1
23
4
5
6
7For flap loaders (= access to CD drive possible)
cleaning method 4 is recommended1
-
7
For description - see following pagesCD PLAYABILITY CHECK1-2
