This is the 29 pages manual for philips mc 147 service manual. Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.
Page: 1 / 29
Extracted text from philips mc 147 service manual (Ocr-read)
Page 1
PCBS LOCATION
FRONT BOARDMAIN BOARD
1-2
Page 2
1-3
AMPLIFIER
Output power ........................................... 2 x 2W RMS
Signal-to-noise ratio .......................... t 60 dBA (IEC)
Frequency response ....................... 125 -“ 16000 Hz
Impedance loudspeakers ........................................... 8 :
CD PLAYER
Frequency range ............................... 125 -“ 16000 Hz
Signal-to-noise ratio ............................................ 65 dBA
TUNER
FM wave range ................................... 87.5 -“ 108 MHz
MW wave range ................................ 531 -“ 1602 kHz
Sensitivity
-“ FM 26 dB sensitivity .......................................... 20 µV
-“ MW 26 dB sensitivity ................................... 5 mV/m
Total harmonic distor tion ..................................... d 5%
TAPE DECK
Frequency response Normal tape (type I) ...... 125 -“ 8000 Hz (8 dB)
Signal-to-noise ratio Normal tape (type I) .................................... 40 dBA
Wow and flutter .............................................. d 0.4% JIS SPEAKERS
Bass reflex system
Dimensions (w x h x d) . 134 x 230 x 152 (mm)
GENERAL INFORMATION
AC Power ..................................... 220 -“ 230 V / 50 Hz
Dimensions (w x h x d) ..
148 x 233 x 216 (mm)
Weight (with/without speaker s) ..................................
......................................................... approx. 3.65 / 1.53 kg
Power consumption Active ........................................................................\
.. 15 W
Standby .................................................................... < 4 W
Specifications and external appearance are
subject to change without notice.
SPECIFICATIONS
