LOCATION OF PCB BOARDS
VERSION VARIATION:
Type/Versions
Features HTS2201
Output Power - 150W
Output Power - 120W
Voltage (110-240V)
Main Board
VFD+USB Board
Type/Versions
Board in used
HTS2201
REPAIR SCENARIO MATRIX:
/93
x
*C = Component Level RepairPower BoardC
C
/93
C
x
POWER PCB
MAIN PCB
VFD PCB
USB PCB
AUX x
x
Page 2
1 - 3
SPECIFICATIONS
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW, CD-R/CD-RW, Audio
CD, Video CD/SVCD, Picture CD, MP3-CD, WMA-CD, DivX-
CD, USB storage device
File Format
Audio ...................................................................... .mp3, .wma
Video .......................................... .divx, .divx ultra, .mpeg, .mpg
Picture ....................................................................... .jpeg, .jpg
Amplifier
Total output power .....................................................................
.......................150 W RMS (30% THD), 120W RMS(10% THD)
Frequency response .................................. 20 Hz-20 kHz /±3dB
Signal-to-noise ratio .................... > 65 dB (CCIR) /(A-weighted)
Input sensitivity ..........................................................................
AUX ............................................................................. 800 mV
Video
Signal system ........................................................ PAL / NTSC
Audio
Sampling frequency ...................................................................
MP3 ................................................ 32 kHz, 44.1 kHz, 48 kHz
WMA ............................................................ 44.1 kHz, 48 kHz
Constant bit rate ........................................................................
MP3 ........................................................ 112 kbps - 320 kbps
WMA ......................................................... 48 kbps - 192 kbps
Radio
Tuning range .................................. FM 87.5-108 MHz (50 kHz)
Signal-to-noise ratio .................................................... FM 50 dB
Frequency response .......................... FM 180 Hz-10 kHz/ ±6dB
USB
Compatibility ....................................................................... USB
Class support ......................... UMS (USB Mass Storage Class)
File system ......................................................... FAT16, FAT32
Maximum memory support .......................................... < 160GB
Main Unit
Power supply .......................................... 110-240V, ~50-60 Hz;
Power consumption ........................................................... 50 W
Standby power consumption ......................................... -‰¤ 0.9 W
Dimensions (WxHxD) ................................ 360 x 58 x 303(mm)
Weight ..............................................................................2.3 kg
Speakers
System ........................................................... full range satellite
Speaker impedance ......................................................... 3 ohm
Speaker drivers ........................................ 76 mm (3) full range
Frequency response ...........................................150 Hz-20 kHz
Dimensions (WxHxD) ............................ 254 x 1001 x 254(mm)
Weight ................................................................... 3.38 kg/each
Cable length ........................................................................ 4 m
Subwoofer
Impedance ..................................................................... 12 ohm
Speaker drivers ....................................... 165 mm (6.5) woofer
Frequency response ...........................................20 Hz-150 kHz
Dimensions (WxHxD) ............................. 123 x 309 x 369 (mm)
Weight ............................................................................3.81 kg
Cable length ........................................................................ 4 m
Laser specification
Type .....................................Semiconductor laser GaAIAs (CD)
Wave length ............... 645 - 665 nm (DVD), 770 - 800 nm (CD)
Output power .............................6 mW (DVD), 7 mW (VCD/CD)
Beam divergence .................................................... 60 degrees.
Specifi cations subject to change without prior notice.
