AMPLIFIER
RMS output power1KHz (Low channel-both channels driven) ................................................................. 100 W per channel
10KHz (High channel-both channels driven) .... .......................................................... 100 W per channel
Total output power ........................................... 580 W
Signal-to-noise ratio .......................... 67 dB A (IEC)
Frequency response .......................... 60 - 16000 Hz
Input sensitivity
AUX ................................................. 1500mV/2000mV
Output Speakers .................................................................... 3 -¦
(1) (3 -¦, 1 kHz, 10% THD)
CD/MP3-CD PLAYER
Number of programmable tracks ......................... 40
Frequency response ............. 60 - 16000 Hz -3dB
Signal-to-noise ratio ....................................... 75 dB A
Channel separation .......................... 50 dB (1 kHz)
Total harmonic distor tion ................................. < 1.5%
MPEG 1 Layer 3 (MP3-CD) .......... MPEG AUDIO
MP3-CD bit rate ....................................... 32-256 kbps
(128 kbps advised)
Sampling frequencies ...................... . 32, 44.1, 48 kHz
TUNER
FM wave range ................................... 87.5 - 108 MHz
AM wave range (9 kHz) ............... 531 - 1602 kHz
AM wave range (10 kHz) ............. 530 - 1700 kHz
Tuning grid ............................................................ 9/10 kHz
Number of presets ........................................................ 40
Antenna FM ....................................................................... 75 -¦ wire
AM .............................................................. Loop antenna USB PLAYER
USB ................................................................... 12Mb/s, V1.1
......................................... suppor t MP3 and WMA files
Number of albums/folders ................. maximum 99
Number of tracks/titles ...................... maximum 999
SPEAKERS
System 2-way; double por t bass reflex
Impedance ........................................................................\
3 -¦
Woofer ................................................................... 2 x 5.25
Tweeter ................................................................... 2 x 1.75
Dimensions (w x h x d) . 225 x 430 x 275 (mm)
Weight .......................................................... 4.928 kg each
SUBWOOFER
Impedance ........................................................................\
6 -¦
Subwoofer driver ............................................................. 8
Subwoofer output power ................................. 180 W
Dimensions (w x h x d)274 x 430 x 342.3 (mm)
Weight ...................................................................... 6.747 kg
GENERAL
Material/finish ................................... Polystyrene/Metal
AC Power ........................... 110 - 127 / 220 - 240 V;
....................................................... 50/60 Hz, Switchable
Power Consumption
Active ........................................................................\
130 W
Standby .................................................................. -€ 20 W
Dimensions (w x h x d) .. 265 x 345 x 382 (mm)
Weight (without speake rs) ........................... 8.505 kg
Specifications and external appearance are
subject to change without notice.
TECHNICAL SPECIFICATION
1 - 2
