Page 1
1-2
ETF7
BOARD
TRAFO
PR I.
BO ARD
TRA FO
SEC.
B O
ARD
M A
IN S
BO AR
D
(/21/22 O nly)
C
O M
BI B O
AR D
FRONT
BOARD
MPEG BOARD CD BOARD
LOCATION OF PC BOARDS
/55
Karaoke x
News
RDS
Incredible Surround
Rotary Encoder (volume control) x
Jog Shuttle x
V oltage Selector x
Aux / CDR Input x
V ideo Output x
Headphone Socket x
Line Output
Subwoofer Output
Surround Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display x
ECO Standby - Dark
Combi - Non-Cenelec Tuner x
Combi - Cenelec Tuner
Mains Board (Chapter 5) x
MP3-CD Play x
V ideo CD Play x
VERSION VARIATIONS:
T ype /Versions: FWV357
Features &
Board in used:
/98
x
x
x
x x
x x
x
x
x
x
x
Page 2
1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable
Mains frequency : 50/60Hz
Power consumption : < 80W Active< 15W at Standby with Clock on
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 365mm
TUNER:
FM
T uning range : 87.5-108MHz
Grid : 50kHz
100kHz
IF frequency : 10.7MHz
± 20kHz
Aerial input : 75 -„¦ coaxial
Sensitivity at 26dB S/N : < 7 µV
Selectivity at 600kHz bandwidth : > 25dB
IF rejection : > 60dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8 µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
T uning range : 531-1602kHz
530-1700kHz
Grid : 9kHz/10kHz
IF frequency : 450kHz
± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.4mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
AMPLIFIER:
Output power : 2 x 40W RMS
2)
2 x 33W FTC 3)
Frequency response within -3dB : 50Hz-15kHz
Dynamic Bass Boost : DBB ON, DBB 1, DBB 2, DBB 3
4)
Digital Sound Control : Jazz, Techno, Optimal, Rock 4)
Headphone output, R LOAD = 32 -„¦:15mW ± 2dB
Input sensitivity, R
S = 600 -„¦
Aux / CDR : 500mV / 1.0V Mic : {3.5mV} CASSETTE RECORDER:
Number of track : 2 x 2 stereo
T
ape speed : 4.76 cm/sec +2.5/-1.5%
W ow and flutter : < 0.4% DIN
Fast-wind/rewind time C60 : 130 sec
Bias system : 78kHz
± 10kHz
Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz
Signal to noise ratio Type I : > 48dBA
VCD/COMPACT DISC:
Audio Performance:
Measurement done at output conn. of the 3CDC module.
Frequency response within 3dB : 20Hz - 20kHz
Output level (in Vrms) : 500mV
± 1.5dB, R out = 100 -„¦
Signal/Noise ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel unbalance at 1kHz :
±1dB
Channel separation at 1kHz : > 60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode on the disc)
MPEG 1 Layer 3 (MP3-CD) : MPEG AUDIO
MP3-CD bit rate : 56-256 kbps
MP3-CD sampling frequencies : 32kHz, 44.1kHz,
48kHz
Recording Format : ISO 9660
UDF format not supported.
V ideo Performance
(for VCD version only) :
V ideo output level : 1.0V
± 0.2V
Luminance non-linear distortion : < 0
± 5%
Luminance S/N ratio : > 50dB
1) Default setting is OFF, to switch on please refer page 3-1.
2) 6 -„¦ , 1kHz, 10% THD
3) 6-„¦ , 60-12500Hz, 10% THD
4) Frequency response in each setting is software controlled.
