SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable
Mains frequency : 50/60Hz
Power consumption : < 35W Active
< 15W at Standby with Clock on
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 365mm
TUNER:
FM
Tuning range : 87.5-108MHz
Grid : 50kHz
100kHz(switchable)
IF frequency : 10.7MHz ± 20kHz
Aerial input : 75 1 coaxial
Sensitivity at 26dB S/N : < 22µV
Selectivity at 600kHz bandwidth : > 25dB
IF rejection : > 60dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 23.5dBf
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz or
530-1700kHz
Grid : 9kHz or
10kHz
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial 18.1µH
Sensitivity at 26dB S/N : < 4.4mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
AMPLIFIER:
Output power : 2 x 20W
1) RMS
Frequency response within -3dB : 60Hz-16kHz
Dynamic Bass Boost : DBB Off, DBB 1, DBB 2, DBB 3
2)
Digital Sound Control : Jazz, Techno, Optimal, Rock 2)
Headphone output, R LOAD = 32 1: 15 mW ± 2dB
Input sensitivity, R
S = 600 1
Aux / CDR : 500mV / 1.0V
Mic : 3.5mVCASSETTE RECORDER:
Number of track : 2 x 2 stereo
Tape speed : 4.76 cm/sec +2.5/-1.5%
Wow and flutter : < 0.4% DIN
Fast-wind/rewind time C60 : 130 sec
Bias system : 78kHz ± 10kHz
Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz
Signal to noise ratio Type I : > 48dBA
VCD/
COMPACT
DISC:
Audio Performance:
Meas
urement
done at output conn. of the 3CDC module.
Fr equency response within ± 3dB : 20Hz - 20kHz
Outp
ut level
(in Vrms) : 500mV ± 1.5dB, R
out = 1
00 1
Signal/Noise ratio (A-weighted) : > 80dBA
Dist
ortion a
t 1kHz : < 0.003%
Ch
annel unbalance at 1kHz :±1d
B
Chan
nel sepa
ration at 1kHz : > 60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode
on the disc)
1) 6 1, 1kHz, 10% THD
2) Fr equency response in each setti
ng is software controlled.
MPEG 1 Layer 3 (MP3-CD) : MPEG AUDIO
MP3-CD bit rate : 56-256 kbps
MP3-CD sampling frequencies : 32kHz, 44.1kHz,
48kHz
Recording Format : ISO 9660
UDF format not supported.
Video Performance :
Video output level : 1.0V ± 0.2Vpp
Luminance non-linear distortion : < 0 ± 5%
Luminance S/N ratio : > 50dB
