Service Information
Product Service Group CE Audio
3139 785 30096
2002 - 07 - 15
FW-C399
A02 - 176
CHANGES DURING PRODUCTION
3CDC MODULE
* From production wk224 onwards a new 3CDC-LLC-DA11
module with Sanyo DA11 Drive is introduced as an alterna-
tive module.
The new module can be recognized by:
a) the label on the left side of the module
b) the additional housing over one of the toothed wheels as
shown in the picture below
Enclosed is the complete new chapter 10 for the new
module.
Already published Service Informations: A02-1593139 785 30073
MMPWR 100W MODULE
* F rom wk23 8 on wards (begin with /37 versions) the foll owing
changes are make to improve reliability of the Power ampli-
fier.
Delete: 2360, 2363, 3371 and 3374
Add: 2361 5322 121 42386 100nF 10% 50V 2364 5322 121 42386 100nF 10% 50V
3372 4822 053 10478 4R7 5% 1W
3374 4822 053 10478 4R7 5% 1W
Change: 2362 to 4822 121 43856 4,7nF 10% 50V
2365 to 4822 121 43856 4,7nF 10% 50V
7330 to 9322 182 31682 STK442-110i
All components are already provided as provision in the
existing schematics & layout drawings.
