Page 1
1-2
LOCATION OF PRINTED CIRCUIT BOARDS
ETF7
BOARD
MAINS
BOARD
POWER
BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
CD KEY BOARD
FRONT
BOARD
KARAOKE
BOARD
AF9
BOARD
HEADPHONE
BOARD
CD
BOARD
/21 /22 /30 /34 /37
Aux in /CDR in xxxxx
Line Out
Surround Out
Subwoofer Out xxxxx
Digital Out xxxxx
Matrix Surround
CD Text
Dolby B
RDS x x
News x x
Dolby Pro Logic (DPL)
Incredible Surround xxxxx
Karaoke Features x
V oltage Selector x
ECO Power Standby (Clock Display Off) x x x
ECO6 Tuner Board - Systems Non-Cenelec x x x x
ECO6 Tuner Board - Systems Cenelec x
Center/Surround Channel
Note: 3CDC-LC-MB Module is mechanically the same as 3CDC-LC Module except the \
schematics, layouts & electrical parts list related to the CDC Board.The CDC Board (recognized by 12NC :\
3103 303 34522 printed on the Board)
is introduced as an alternative to supplement for the shortage of Servo \
IC TDA7073A.
VERSION VARIATIONS:
T
ype /Versions: FW-C380
Features &
Board in used:
Page 2
1-3
SPECIFICA TIONS
GENERAL:
Mains voltage : 1 10-127V/220-240V Switchable for /21/21M
120V for /37
220V for /33
220-230V for /22/34
230-240V for /30
Mains frequency : 50/60Hz
Power consumption : < 1W at ECO Power Standby :< 15W at Standby
: 90W at Active
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 390mm
TUNER:
FM
T uning range : 87.5-108MHz
65.81-74MHz for /34
1)
Grid : 50kHz (& 30kHz for /34)
100kHz for /37
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75-„¦ coaxial
75 -„¦ click fit for /37
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 25dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
T uning range : 531-1602kHz
530-1700kHz for /21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.0mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
LW
T uning range : 153-279kHz /22
Grid : 3kHz
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : [< 7.0mV/M]
Selectivity at 18kHz bandwidth : [> 24dB]
IF rejection : [> 30dB]
Image rejection : [> 30dB]
Distortion at RF=50mV, m=80% : [< 5%] AMPLIFIER:
Output power (6
-„¦, 1kHz, 10% THD)
L & R : 2 x 60W
Output power (6 -„¦, 60Hz-12.5kHz, 10% THD) /37
L & R : 2 x 45W
Frequency response within -3dB : 60Hz-16kHz
Digital Sound Control (DSC) : Optimal, Jazz, Rock, Techno
V irtual Environment Control (VEC) : Hall, Concert, Cinema
Dynamic Bass Boost (DBB) : DBB 1, DBB 2, DBB 3, DBB OFF
Incredible Surround : IS ON, IS OFF
Input sensitivity Aux in : 500mV ± 3dB at 600 -„¦
CDR in : 1V ± 3dB at 600 -„¦
Mic : {3mV ± 3dB at 600 -„¦}
Output sensitivity
Subwoofer out : 1.5V ± 2dB at 22 k -„¦
Headphone output at 32 -„¦:15mW ± 2dB
Digital (Coax) out : IEC 958, 44.1kHz
CASSETTE RECORDER:
Number of track : 2 x 2 stereo
T ape speed : 4.76 cm/sec ± 2%
W ow and flutter : < 0.4% DIN
Fast-wind/Rewind time C60 : 130 sec
Bias system : 75kHz ± 10kHz
Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz
Signal to Noise Ratio (Type I) : > 48dBA
COMPACT DISC:
Measurement done at output conn. of the CDC module.
Frequency response : < ±1.5dB for 20Hz-20kHz
Output Voltage (in Vrms) : 550mV ± 1dB unloaded
Signal to Noise Ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel Unbalance : < ±1dB
Channel Separation (1kHz) : >60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode on the disc)
[....] Values indicated are for "ECO6 Cenelec Board" only.
{....} Values for /21/21M only
1) Default setting is OFF, to switch on please refer page 3-4.
