1-2
ETF7
BOARD
PRI.
BO
MAINS
BOARD
COMBI BOARD
FRONT
BOARD
LOCATION OF PCBs
/21M /22 /30
Karaoke x
News x
RDS x
Incredible Surround
Rotary Encoder (volume control) x x x
Jog Shuttle x x x
Voltage Selector x
Aux / CDR Input x x x
Digital Output
Headphone Socket x x x
Line Output
Subwoofer Output
Surround Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display x x x
ECO Standby - Dark x
Combi - Non-Cenelec Tuner x x x
Combi - Cenelec Tuner x VERSION VARIATIONS:
Type /Versions: FW-C330
Features &
Board in used:
/33
x
x
x
x xx/34
x
x
x
x
x
x
x
xx
BO
AR
D C
D
Page 2
1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable for /21M
220-230V for /22/30/33/34
Mains frequency : 50Hz
50/60Hz for /21M
Power consumption : < 35W Active
< 15W at Standby with Clock on
< 1W at ECO Standby /22
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 365mm
TUNER:
FM
Tuning range : 65.81-74.0MHz for /34
87.5-108MHz for /21M/22/30/34
Grid : 50kHz
30kHz(switchable) for /34
50kHz(switchable) for /34
100kHz for /21M
IF frequency : 10.7MHz ± 20kHz
Aerial input : 75-„¦ coaxial
Sensitivity at 26dB S/N : < 22µV
Selectivity at S9/300kHz bandwidth : > 25dB
IF rejection : > 60dB [80dB]
Image rejection : > 25dB [75dB]
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 23.5dBf
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHz for /21M
Grid : 9kHz
10kHz for /21
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.4mV/M [4.0mV/M]
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%AMPLIFIER:
Output power : 2 x 20W
1) RMS
Frequency response ±3dB±5% : 60Hz-16kHz
Dynamic Bass Boost : DBB Off, DBB 1, DBB 2, DBB 3
3)
Digital Sound Control : Jazz, Techno, Optimal, Rock 3)
Headphone output, R LOAD = 32-„¦:15mW ± 2dB
Input sensitivity, R
S = 600-„¦
Aux / CDR : 500mV / 1.0V
Mic : {3.5mV}
CASSETTE RECORDER:
Number of track : 2 x 2 stereo
Tape speed : 4.76 cm/sec +2.5/-1.5%
Wow and flutter : < 0.4% DIN
Fast-wind/rewind time C60 : 130 sec
Bias system : 78kHz ± 10kHz
Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz
Signal to noise ratio Type I : > 48dBA
COMPACT DISC:
Measurement done at output conn. of the CDC module.
Frequency response within ± 1.5dB : 20Hz - 20kHz
Output level (in Vrms) : 500mV ± 1dB, R
out = 100-„¦
Signal/Noise ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel unbalance at 1kHz :±1dB
Channel separation at 1kHz : > 70dB
De-emphasis : 0 or 15/50 mS (Switched by subcode
on the disc)
{....} Values for /21M/33 only
[....] Values for Cenelec Tuner only
1) 6-„¦, 1kHz, 10% THD
2) Frequency response in each setting is software controlled.
