Extracted text from philips fw c 255 service manual 1 (Ocr-read)

Page 2

1-2

LOCATION OF PC BOARDS

VERSION VARIATIONS:
Type /Versions: FW-0255
Features & /30 /33 /37
Board in used:
Karaoke
News
FIDS
Incredible Surround
Rotary Encoder (volume control)
J Shuttle
Voltage Selector
Aux Input
Digital Output
Headphone Socket
Line Output
Subwooter Output
Surround Output
Matrix Surround Loudspeakers
Standby - FTD Clock Display
ECO Standby - Dark
Combi - Non-Cenelec Tuner
Combi - Cenelec Tuner
