Page 1
SPR 00 00551-2
ETF
BOARD
MAINS
BOARD
TUNER
BOARD
COMBI BOARD
H/P
BOARD
KARAOKE
BOARD
FRONT
BOARD
CD BOARD CD KEY BOARD
LOCATION OF PC BOARDS
/21 /21M /30 /33
Incredible Surround
Karaoke x x
News
RDS
Rotary Encoder (volume control) x x x x
Jog Shuttle
V oltage Selector x x
Aux Input x x x x
Digital Output
Headphone Socket x x x x
Line Output
Subwoofer Output
Surround Output
Matrix Surround Loudspeakers
Standby - Clock Display x x x x
Standby - Dark
T uner board - ECO5 Sys x x x x
T uner board - Tuner 95
Combi board 12W version
Combi board 18W version x x x x
Combi board 25W version
VERSION VARIATIONS:
T
ype /Versions: FW-C200
Features &
Board in used:
Page 2
SPR 00 0056
1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 1 10-127V/220-240V Switchable for /21/21M
120V for /37
220-230V for /22/34
230-240V for /30
Mains frequency : 50/60Hz
Power consumption : < 15W at Standby < 44W Active
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 320mm
TUNER:
FM
T uning range : 87.5-108MHz
65.81-74MHz for /34
1)
Grid : 50kHz (& 30kHz for /34)
100kHz for /37
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75-„¦ coaxial
300 -„¦ click fit for /37
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 30dB
Image rejection : > 25dB [> 60dB]
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
T uning range : 531-1602kHz
530-1700kHz for /21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.0mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 40dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
LW
T uning range : 153-279kHz for /22
Grid : 3kHz
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : [< 7.0mV/M]
Selectivity at 18kHz bandwidth : [> 30dB]
IF rejection : [> 25dB]
Image rejection : [> 35dB]
Distortion at RF=50mV, m=80% : [< 5%] AMPLIFIER:
Output power (6
-„¦, 1 kHz, 10% THD) : 2 x 20W ± 1dB
Frequency response within -3dB : 50Hz-15kHz
Dynamic Bass Boost : DBB ON, DBB Off
2)
Digital Sound Control : Jazz, Techno, Optimal, Rock 2)
Headphone output at 32 -„¦:16mW
Input sensitivity Aux/Line-in : 700mV ± 2dB at 600 -„¦
Mic : {3.5mV}
CASSETTE RECORDER:
Number of track : 2 x 2 stereo
T ape speed : 4.76 cm/sec ± 2%
W ow and flutter : < 0.4% DIN
Fast-wind/rewind time C60 : 130 sec
Bias system : 75kHz ± 10kHz
Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz
Signal to noise ratio Type I : > 48dBA Type II : > 52dB
COMPACT DISC:
Measurement done at output conn. of the CDC module.
Frequency response within ± 1.5dB : 20Hz - 20kHz
Output level (in Vrms) : 550mV, Z
out = 100 -„¦
Signal/Noise ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel unbalance at 1kHz : ±1dB
Channel separation at 1kHz : > 60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode on the disc)
[....] Values indicated are for "Tuner 95 Board" only
{....} Values for /21/21M only
1) Default setting is OFF, to switch on please refer page 3-4.
2) Frequency response in each setting is software controlled.
