1-3
SPECIFICATIONS
GENERAL:
Mains voltage :
230V ± 10% for /22/25
Mains frequency : 50/60Hz /21
Po we r consumption :
-‰¤ 15 W at Standby /21
-‰¤ 0.5W at ECO Standby /22/25
30W Active /22/25
Clock accuracy : < 4 seconds per day
Dimension centre unit
:265 x 310 x 330mm
TUNER:
FM
Tuning range:87.5-108MHz
Grid : 50kHz
IF frequency : 10.7MHz ± 20kHz
Aerial input : 75-„¦ coaxial
Sensitivity at 26dB S/N : < 22µ V
Selectivity at 300kHz bandwidth : > 25dB
Image rejection,98MHz : > 40dB /21
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 23.5µ V
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 530-1700kHz /21
Grid : 10kHz /21
IF frequency : 450kHz ± 1kHz
Aerial input : Fr ame aerial, 18.1 µH
Sensitivity at 26dB S/N : < 4.4mV/M
Selectivity at 300kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%AMPLIFIER:
Output power
1) :2 x 3.5W ± 1dB
Fr equency response within -3dB : 50Hz-15kHz
Dynamic Bass Boost : DBB1, DBB2, DBB3, DBB Off
2)
Digital Sound Control : Jazz, Techno, Optimal, Rock 2)
Headphone output at 32W : 900mV ± 1dB (max Vol.)
CASSETTE RECORDER:
Number of track : 2 x 2 stereo
Ta p e s peed : 4.76 cm/sec +2.5/-1.5
%
Wow a nd flutter : < 0.35% DIN
Fa st-wind/rewind time C60 : 130 sec
Bias system : 75kHz ± 5kHz
Rec/Pb frequency response within 8dB : 80Hz - 10kHz
Signal to noise ratio (A-weighted) :
-‰¥ 48dBA
COMPAC T DISC:
Measurement done at output conn. of the CDC module.
Fr equency response within ± 1.5dB : 20Hz - 20kHz
Output level (in Vrms) : 550mV, Z
out = 100-„¦
Signal/Noise ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel unbalance at 1kHz :± 1dB
Channel separation at 1kHz : > 60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode
on the disc)
1) 3-„¦ , 1 kHz, 10% T HD
2) Fr equency response in each setting is software controlled.
Weight (w/o speakers) : 4.6KgFrequency response
:80 - 12500Hz (8dB)
110-127V/220-240V Switchable for /21
25W Active /21
50Hz /22/25
-‰¤ 11W at Standby /22/25
> 80dB /22/25
:531-1602kHz /22/25
:9kHz /22/25
