Page 1
3 EN
Contents
1 Impor tant 4
Safety 4
Notice 4
2 Y our car audio system 6
Introduction 6
What's in the box 6
Over view of the main unit 7
Over view of the remote control 8
3 Install the ca r audio 10
Connect 10
Mount into dashboard 11
Attach the front panel 12
Install remote control batter y 12
4 Get star ted 13
Turn on and turn off 13
Adjust volume 13
Mute 13
Set clock 13
5 Pla y audio/video/picture 14
Load and eject discs 14
Inser t and remove USB device 15
Skip/search 15
Select Language 16
Select audio language 16
Intro play 16
Repeat play 16
Random play 17
Zoom 17
6 Radio 17
Manual tune to a radio station 17
Auto tune to a radio station 17
Store stations manually 17
Store stations automatically 18
Select the preset station 18
Play with RDS 18
7 Adjust sound 19
Dynamic Bass Boost 19
MAX sound 19
Select equalizer settings 20
Select listening zone 20
Other sound settings 20
8 System settings 21
Adjust general settings 21
Select video settings 22
Select language settings 23
Adjust turner settings 23
9 Other settings 24
Turn on or off the screen backlight 24
Select Video Output format 24
Listen to other devices 24
Set rear view camera 24
Reset 24
Replace fuse 25
10 Pr oduct information 26
General 26
Disc player 26
Tuner 26
LCD 26
Compatible USB devices 26
Suppor ted formats 26
Unsuppor ted formats 27
11 T roubleshooting 28
CED230_51_UM_V2.1.indb 3 8/14/2012 4:37:41 PM
English
Page 2
4 EN
1 Impor tant
Safety
- Read and understand all instructions
before you use the apparatus. If damage is
caused by failure to follow instructions, the
warranty does not apply.
- Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
- This unit is designed for negative ground
(ear th) 12 V DC operation only.
-
To reduce the risk of traffic accident, do no
watch video during driving.
- To ensure safe driving, adjust the volume to
a safe and comfor table level.
- Improper fuses can cause damage or
fire. When you need to change the fuse,
consult a professional.
- Use only the supplied mounting hardware
for a safe and secure installation.
- To avoid shor t circuit, do not expose the
apparatus, remote control or remote
control batteries to rain or water.
- Never inser t objects into the ventilation
slots or other openings on the apparatus.
- Never place any objects other than discs
into the disc tray/slot.
- Visible and invisible laser radiation when
open. Avoid exposure to beam.
- Risk of damage to the screen! Never touch,
push, rub or strike the screen with any
object.
- Never use solvents such as benzene,
thinner, cleaners available commercially, or
anti-static sprays intended for discs.
- Clean the apparatus with soft, damp cloth.
Never use substances such as alcohol,
chemicals or household cleaners on the
apparatus.
- The product/remote control may contain
a coin/button type batter y, which can be
swallowed. Keep the batter y out of reach
of children at all times! If swallowed, the
batter y can cause serious injur y or death.
Severe internal burns can occur within two
hours of ingestion.
- If you suspect that a batter y has been
swallowed or placed inside any par t of the
body, seek immediate medical attention.
- When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the batter y
compar tment is completely secure after
you replace the batter y.
- If the batter y compar tment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
Notice
The making of unauthorized copies of copy-
protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
