Page 1
1-1 TECHNICAL SPECIFICATION
General:
Mains voltage : 220V-230V / 50-60Hz for /00
110V-240V /50-60Hz for /01C
120V / 60Hz for /17
Power consumption :²18W
²1W in stand by
Input / Output:
Analog in:
input sensitivity :²500mV rms max. input voltage : 2,8V rms input impedance : 47kW
Analog out:
output level : 2V
rms ±2dB at no load
output impedance : 200W
Microphone in:
input sensitivity :²1mV
rms max. input voltage : 50mV rms input impedance : 2kW
Digital in (acc. IEC958):
input level : 0,5V
pp input impedance : 75W
Digital out (acc. IEC958):
output level : 0,5V
pp output impedance : 75W
Headphone:
output level : 4,4V
pp at no load
output impedance : 120½
frequency response : 20 - 20.000 Hz ±3dB
distortion : 0,01% at 1 kHz and -6dB output level at 120W
channel difference :²3dB at 1 kHz
channel crosstalk : -50dB at 1kHz
AUDIO PERFORMANCE
3CDC module:
To be measured on ANALOG OUT socket.
frequency response : 20 - 20.000 Hz ±0,6dB
signal/noise ratio :³115dB (120dB A-weighted)
distortion : -88dB at 1 kHz (-91dB typ.)
channel difference :²0,5dB at 1 kHz
channel crosstalk : -115dB at 1kHz(-120dB typ.)
de emphasis : 0 or 15/50µs switched automatically by subcode on the disc
laser
output power : 500µW
wave length : 780 ±20nm
CD-RW module: To be measured on ANALOG OUT socket.
frequency response : 20 - 20.000 Hz ±0,3dB (±1dB recording)
signal/noise ratio :³95dB (98dB A-weighted)
distortion : -86dB at 1 kHz (-83dB recording)
channel difference :²0,5dB at 1 kHz
channel crosstalk : -86dB at 1kHz (-74dB recording)
de emphasis : 0 or 15/50µs switched automatically by subcode on the disc
laser (laser class 3B)
output power : 1mW max. during reading
20mW max. during writing
wave length : 780 ±20nm
Page 2
1-2
SYSTEM CODE
RC KEY
yCOMMAND CODE
CD
20 26 12CDR
BRIGHTNESS
Standby
20 26 71
TRACK INCR.- 26 114
CD TEXT20 26 88
120 26 01
220 26 02
320 26 03
420 26 04
520 26 05
620 26 06
720 26 07
820 26 08
920 26 09
TEXT EDIT20 26 82
020 26 00
PROGRAM20 26 36
NO20 26 49
YES20 26 87
PLAY 20 26 53
Á
2
920 26 33
ª
20 26 32
STOP 20 26 54
520 26 50
6
;20 26 52
PAUSE 20 26 48
SHUFFLE20 26 28
REPEAT20 26 29
CD120 20 55
CD220 20 56
CD320 20 57
CDR26 26 63
RC5 code RC283505, 130300
Remote Control: RC5 commands RC283505
TECHNICAL SPECIFICATION
L
R
LEVEL METERe.g. Sennheiser UPM550
with FF-filter
S/N and distortion metere.g. Sound Technology ST1700B
DUT
CD
Use Audio Signal Disc SBC429 4822 397 30184
(replaces test disc 3)
MEASUREMENT SETUP
