Philips bx 135 b service manual

Page 2

311353-00, -63, -95

Fig. 1 Cable drive.

Fig.1 2 Coil comeotions.

Fig. 3 Circuit diagram.(BX135E-OO)

Figa 4 Diagram of the RJ. parts (mums-63).
Fig. 5 Diagram of the LP. parts (mums-95).
Fig. 6 Wiring diagram (under) 151353-00-

Fig. 7 Wiring diagram (under) MUSE-63c

Fig, 8 Wiring diagram (under) 3x1353-95.
Fig, 9

Fig.1o Wiring diagram (above

Wiring diagram (above; EMBED-00.
BX1353-6}95 J

W

A. LF. 23"

1a
2.

3.
4.

5.

6.

Turn the volume control to maximum and the variable capacitor to
minimum capacitance.

Connect a voltmeter via a trimming transformer to the loudspeaker
temimls.

Screw the cores of the LF. filters nearly full out.

Apply a. modulated signal of 452 kc/s via a. 33000 9? capacitor to

$3 of B1.

Trim the LE. circuits for maximum output voltage in the following
orders

4th I.F. circuit 58-015
3rd IJ. circuit 57-014
1st IJ. circuit 55-610
2nd. IJ. circuit SS-CH
3m I.F. circuit 57-014

Seal the cores.

B. LP. and oscillator circuits

Tri
lri

the
poi
the

1.
2.

3.

Trimming is done with the aid of trimming points on the dial.
mming point 1 - extreme left trimming point on the dial.
mming point 2 - right trimming point on the dial.

Before starting to trim, check the adjustment of the pointer. With
variable capacitor at minimum, the pointer must be on trimming
nt 1- If not adjust it to the correct position. For all waveranges
following applies:

Volume control at maximum,

Connect a. voltmeter via. a trimming transformer to the loudspeaker
terminals.

Apply the modulated signals via. a dummy serial to the aerial socket
Y1.
