AMPLIFIER
Output power ....................................... 2 x 15 W RMS
Signal-to-noise ratio ....................................... t 70 dBA
Frequency response ...... 20 Hz -“ 20 KHz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeaker s ......................................... 4 :
Impedance headphones ........................................ 32 :
Output power headphones ....................... <50 mW
CD PLAYER
Frequency range ................................ 20 Hz -“ 20 kHz
Signal-to-noise ratio ............................................ 70 dBA
TUNER
FM wave range ................................... 87.5 -“ 108 MHz
AM wave range ................................. 530 -“ 1700 KHz
Antenna
FM ....................................................................... 75 : wire
AM .............................................................. Loop antenna
USB PLAYER/SD/MMC CARD
USB ................................................................... 12Mb/s, V1.1 ......................................... suppor t MP3 and WMA files
Number of albums/folders ................. maximum 99
Number of tracks/titles ...................... maximum 400
Bluetooth
Communication system .......... Bluetooth Standard
ver sion 2.0
Output ............ Bluetooth Standard Power Class 2 Maximum communication range ...... Line of sight
approx. 10m
1)
Frequency band .... 2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Modulation method ................................................. FHSS
Compatible Bluetooth profiles
2)
.............................................................
...... A2DP (Advanced Audio Distribution Profile)
.. AVRCP (Audio Video Remote Control Profile)
Suppor ted codecs
Receive .................... SBC (Sub Band Codec), MP3
Transmit .............................. SBC (Sub Band Codec)
1) The actual range will vary depending on factor s such as
obstacles between devices, magnetic fields around a microwave
oven, static electricity, reception sensitivity, antennas performance,
operating system, software application, etc.
2) Bluetooth standard profiles indicate the purpose of Bluetooth
communication between devices.
*Wireless range: 10m/30ft line of sight, range may vary
depending on actual conditions. Bluetooth
Rdevice with A2DP
(Advanced Audio Distribution Profile) enabled.
GENERAL INFORMATION
AC Power ............................. 100 -“ 240 V / 50-60 Hz
Dimensions (w x h x d) . 206 x 141 x 390 (mm)
Weight ..................................................................... 2.374 kg
Standby power consumption ............................ <7 W
Eco power standby ................................................. <1 W
Specifications and external appearance are
subject to change without notice.
SPECIFICATIONS
