GENERAL
Mains voltage
-/01
-/01 : 120/230 V
Mains frequency
: 50 / 60 Hz
Battery mains : 9 V (R20 x 6)
Power consumption : 18W
AMPLIFIER
Output power mains : 2 x 5 W(CD/Tape/FM)
battery :
:
: 2 x 4 W(AM)
2 x 5 W(CD/Tape/FM)
2 x 4 W(AM)
Speaker impedance
: 2 x 6 ohm
TUNER - FM SECTIONTUNER - AM SECTION
Tuning range : 87.5 - 108 MHz
IF frequency : 10.7 MHz
Sensitivity
: < 15 dBµV at 26dB S/N
Selectivity
: > 20 dB at ±300kHz
IF rejection
: > 50 dB
Image rejection
: > 20 dB Tuning range :
526.5 - 1606.5 kHz
IF frequency : 465 kHz ± 3 kHz
± Sensitivity : < 72 dBµV/m at 26dB
Selectivity : < 16 dB
IF rejection : > 25 dB
Image rejection ratio : < 28 dB
AUDIO CASSETTE RECORDER
Number of tracks : 1 stereo
Tape speed : 4.76 cm/sec +3/-2%
Wow & flutter : < 0.35 % JIS UWTD
Fast wind/rewind C60 : < 130 sec.
Frequency response P/B : 125 - 8000 Hz
S/N ratio : > 36 dB
COMPACT DISC
Frequency response : 100 Hz - 10 kHz
S/N ratio : > 57 dBA
Channel difference 1 kHz : < 2 dB
Channel crosstalk 1 kHz
Z axis
±
X or Y axis : > 15 dB
Shock resistance : 5G
: 5G
2 - 1
SERVICE TOOLS
Audio signal disc SBC 429.......................................................................4822 397 30184
Playability test disc SBC 444...................................................................4822 397 30245
Test disc 5(disc without errors ) +
Test disc 5A(disc with dropout errors, black spots and fingerprints)
SBC 426/426A.....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30 dB level without pause)
.....4822 397 30155
anti-static table mat
large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25m 4822 466 10958
anti-static wristband4822 395 10223
connection box (3 press stud connections, 1M-„¦ ) 4822 320 11307
extendible cable (2m, 2M-„¦ , to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M-„¦ , to connect table mat to connection box) 4822 320 11306
earth cable (1M-„¦ , to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester4822 344 13999
AVAILABLE ESD PROTECTION EQUIPMENT
TECHNICAL SPECIFICATIONS
